Cosel SUTW DC/DC Converter, 24V dc, -24 V dc/ 130 mA, 48V dc Input, 36V Input 3.12 W, PCB, 85 °C Max Temp -40 °C Min

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£14.02

(exc. VAT)

£16.82

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 07 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£14.02
5 - 9£13.60
10 - 24£13.32
25 - 49£13.05
50 +£12.77

*price indicative

RS Stock No.:
130-7953
Mfr. Part No.:
SUTW34812
Brand:
Cosel
Find similar products by selecting one or more attributes.
Select all

Brand

Cosel

Product Type

DC/DC Converter

Output Voltage 1

24, -24V dc

Minimum Input Voltage

36V

Maximum Input Voltage

48V dc

Output Current 1

130mA

Output Current 2

0.13A

Mount Type

PCB

Number of Outputs

2

Ripple and Noise

200mV Pk-Pk

Output Voltage Adjustment Range

±22.8 V dc, ±25.2 V dc

Isolation Voltage

500V ac

Number of Pins

7

Package Type

DIP

Maximum Output Power

3.12W

Depth

23.4mm

Standards/Approvals

cUL, cULus, EN 60950-1, TUV, UL 60950-1, CE

Width

23.4mm

Length

30mm

Weight

8g

Series

SUTW

Maximum Operating Temperature

85°C

Minimum Operating Temperature

-40°C

Efficiency

76%

COO (Country of Origin):
JP

SUTW Series, 3 to 6 W, Dual Output


The SUTW series of isolated DC-DC converters from Cosel are available with a rated output wattage of 3 W, 6 W or 10 W. SUTW isolated DC-DC converters do not feature a built-in aluminium or tantalum electrolytic capacitor, which ensures a high level of reliability. With high frequency switching in a space saving package, this series has a high level of efficiency (74% to 86%, depending on model).

Features and Benefits:


Remote ON/OFF is built in;Adjustable external output voltage;Built-in overcurrent protection circuits;Cooled by convection/forced air;Through hole mounting

Cosel Isolated DC-DC Converters


Standards

UL60950-1, cUL, EN60950-1
