Cosel SUTS DC-DC Converter, 5V dc/ 2A Output, 18 → 36 V dc Input, 10W, PCB Mount, +85°C Max Temp -40°C Min Temp
- RS Stock No.:
- 130-7946
- Mfr. Part No.:
- SUTS102405
- Brand:
- Cosel
Save 9% when you buy 50 units
Subtotal (1 unit)*
£24.99
(exc. VAT)
£29.99
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £24.99 |
| 5 - 9 | £24.24 |
| 10 - 24 | £23.74 |
| 25 - 49 | £23.24 |
| 50 + | £22.74 |
*price indicative
- RS Stock No.:
- 130-7946
- Mfr. Part No.:
- SUTS102405
- Brand:
- Cosel
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage | 5V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Power Rating | 10W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 2A | |
| Mounting Type | PCB Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±5% | |
| Isolation Voltage | 500V ac | |
| Width | 9.15mm | |
| Length | 45.2mm | |
| Depth | 29.3mm | |
| Series | SUTS | |
| Load Regulation | 40mV | |
| Standards Met | CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1 | |
| Efficiency | 85% | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 5V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 10W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 2A | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±5% | ||
Isolation Voltage 500V ac | ||
Width 9.15mm | ||
Length 45.2mm | ||
Depth 29.3mm | ||
Series SUTS | ||
Load Regulation 40mV | ||
Standards Met CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1 | ||
Efficiency 85% | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
