Cosel SUTS DC-DC Converter, 12V dc/ 250mA Output, 36 → 76 V dc Input, 3W, PCB Mount, +85°C Max Temp -40°C Min
- RS Stock No.:
- 130-7767
- Mfr. Part No.:
- SUTS34812
- Brand:
- Cosel
Available to back order for despatch 08/10/2024
Added
Price Each
£22.82
(exc. VAT)
£27.38
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £22.82 |
| 5 - 9 | £22.13 |
| 10 - 24 | £21.68 |
| 25 - 49 | £21.22 |
| 50 + | £20.76 |
- RS Stock No.:
- 130-7767
- Mfr. Part No.:
- SUTS34812
- Brand:
- Cosel
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
SUTS Series, 3 to 6 W, Single Output
The SUTS series of isolated DC-DC converters from Cosel are available with a rated output wattage of 3 W, 6 W or 10 W. These isolated DC-DC converters do not feature a built-in aluminium or tantalum electrolytic capacitor, which ensures a high level of reliability. With high frequency switching in a space saving package, this series has a high level of efficiency (72% to 87%, depending on model).
Features and Benefits:
Remote ON/OFF is built in
Built-in overcurrent protection circuits
Cooled by convection/forced air
Through hole mounting
Standards
UL60950-1, cUL, EN60950-1
Cosel Isolated DC-DC Converters
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 36 → 76 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 250mA |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Output Voltage Adjustment Range | ±5% |
| Isolation Voltage | 500V ac |
| Length | 30mm |
| Width | 9.15mm |
| Depth | 23.4mm |
| Series | SUTS |
| Load Regulation | 100mV |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Standards Met | CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1 |
| Efficiency | 79% |
