TDK-Lambda CC-E DC/DC Converter, 12V dc/ 1 A, 24V dc Input, 24V dc Input 10 W, Through Hole, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 126-3545
- Mfr. Part No.:
- CC10-2412SF-E
- Brand:
- TDK-Lambda
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£27.26
(exc. VAT)
£32.71
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 3 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £27.26 |
| 5 - 9 | £26.43 |
| 10 - 24 | £25.61 |
| 25 - 49 | £24.82 |
| 50 + | £23.99 |
*price indicative
- RS Stock No.:
- 126-3545
- Mfr. Part No.:
- CC10-2412SF-E
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Minimum Input Voltage | 24V dc | |
| Maximum Input Voltage | 24V dc | |
| Output Current 1 | 1A | |
| Output Current 2 | 1A | |
| Mount Type | Through Hole | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 15 V | |
| Isolation Voltage | 500V ac | |
| Number of Pins | 7 | |
| Maximum Output Power | 10W | |
| Package Type | DIP | |
| Series | CC-E | |
| Standards/Approvals | CE, cULus, EN 60950-1, NEMKO, UL CSA 60950-1 | |
| Weight | 10g | |
| Length | 35.56mm | |
| Depth | 8.5mm | |
| Width | 17.52mm | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 87% | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Minimum Input Voltage 24V dc | ||
Maximum Input Voltage 24V dc | ||
Output Current 1 1A | ||
Output Current 2 1A | ||
Mount Type Through Hole | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 15 V | ||
Isolation Voltage 500V ac | ||
Number of Pins 7 | ||
Maximum Output Power 10W | ||
Package Type DIP | ||
Series CC-E | ||
Standards/Approvals CE, cULus, EN 60950-1, NEMKO, UL CSA 60950-1 | ||
Weight 10g | ||
Length 35.56mm | ||
Depth 8.5mm | ||
Width 17.52mm | ||
Minimum Operating Temperature -40°C | ||
Efficiency 87% | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- JP
CC10-E Series, 10 W Single Output
No tantalum or dielectric capacitors
Through-hole type
Operating temperature range: -40 to +85°C
