MEAN WELL DPB DC/DC Converter, 15V dc/ 200 A, 48V dc Input, 48V dc Input 6 W, Through Hole, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 611-373
- Mfr. Part No.:
- DPBW06G-15
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£7.33
(exc. VAT)
£8.80
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 33 unit(s) shipping from 19 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £7.33 |
*price indicative
- RS Stock No.:
- 611-373
- Mfr. Part No.:
- DPBW06G-15
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 15V dc | |
| Maximum Input Voltage | 48V dc | |
| Minimum Input Voltage | 48V dc | |
| Output Current 1 | 200A | |
| Output Current 2 | 200A | |
| Output Voltage 2 | 15V dc | |
| Mount Type | Through Hole | |
| MTBF | 1850kH | |
| Number of Outputs | 1 | |
| Ripple and Noise | 100mV Pk-Pk | |
| Isolation Voltage | 1.5kV | |
| Number of Pins | 8 | |
| Maximum Output Power | 6W | |
| Package Type | SIP | |
| Length | 21.8mm | |
| Standards/Approvals | EAC TP TC 020/2011 (EAC TP TC 004 for 48Vin type only) approved | |
| Depth | 11.1mm | |
| Width | 9.2mm | |
| Series | DPB | |
| Weight | 4.5g | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 89% | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type DC/DC Converter | ||
Output Voltage 1 15V dc | ||
Maximum Input Voltage 48V dc | ||
Minimum Input Voltage 48V dc | ||
Output Current 1 200A | ||
Output Current 2 200A | ||
Output Voltage 2 15V dc | ||
Mount Type Through Hole | ||
MTBF 1850kH | ||
Number of Outputs 1 | ||
Ripple and Noise 100mV Pk-Pk | ||
Isolation Voltage 1.5kV | ||
Number of Pins 8 | ||
Maximum Output Power 6W | ||
Package Type SIP | ||
Length 21.8mm | ||
Standards/Approvals EAC TP TC 020/2011 (EAC TP TC 004 for 48Vin type only) approved | ||
Depth 11.1mm | ||
Width 9.2mm | ||
Series DPB | ||
Weight 4.5g | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
Efficiency 89% | ||
The MEANWELL 6W isolated and regulated module type DC-DC converter with SIP8 package. It features international standard pins, a high efficiency up to 89%, wide working temperature range -40 to +85°C, 1.5KVDC I/P-O/P isolation voltage, continuous-mode short circuit protection, etc. The models account for different input voltage 9 to 36V and 18 to 75V 4:1 wide input range, and various output voltage, 3.3V, 5V, 12V, 15V for single output and ±5V, ±12V, ±15V for dual outputs, which are suitable for all kinds of systems, Such as industrial control, telecommunication field, distributed power architecture, and so on.
No minimum load required
High efficiency up to 89%
1.5KVDC I/O isolation
Remote ON/OFF control
3 years warranty
