TRACOPOWER THN 10UIR DC/DC Converter, 5.1V dc/ 3000 mA, 160V dc Input, 9V Input 10 W, PCB, 95 °C Max Temp -40 °C Min
- RS Stock No.:
- 608-887
- Mfr. Part No.:
- THN 10-7211UIR
- Brand:
- TRACOPOWER
Subtotal (1 unit)*
£32.59
(exc. VAT)
£39.11
(inc. VAT)
FREE delivery for orders over £60.00
- 10 unit(s) shipping from 11 May 2026
Units | Per unit |
|---|---|
| 1 + | £32.59 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 608-887
- Mfr. Part No.:
- THN 10-7211UIR
- Brand:
- TRACOPOWER
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 5.1V dc | |
| Product Type | DC/DC Converter | |
| Minimum Input Voltage | 9V | |
| Maximum Input Voltage | 160V dc | |
| Output Current 1 | 3000mA | |
| Output Current 2 | 1000mA | |
| Output Voltage 2 | -5V | |
| Mount Type | PCB | |
| Input Ratio | 12:1 | |
| MTBF | 1928000h | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | -10 to 20 % | |
| Ripple and Noise | 75mV Pk-Pk | |
| Number of Pins | 7 | |
| Isolation Voltage | 3000V | |
| Maximum Output Power | 10W | |
| Package Type | 1 x 1 in | |
| Depth | 9.9mm | |
| Length | 25.4mm | |
| Standards/Approvals | EN 45545-2, EN 50155, EN 61373, IEC 62368-1, UL 62368-1 | |
| Width | 20.32mm | |
| Series | THN 10UIR | |
| Weight | 16.1g | |
| Better World Claim | Concentrated or Compact Solution | |
| Better World Product | Yes | |
| Maximum Operating Temperature | 95°C | |
| Efficiency | 88% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 5.1V dc | ||
Product Type DC/DC Converter | ||
Minimum Input Voltage 9V | ||
Maximum Input Voltage 160V dc | ||
Output Current 1 3000mA | ||
Output Current 2 1000mA | ||
Output Voltage 2 -5V | ||
Mount Type PCB | ||
Input Ratio 12:1 | ||
MTBF 1928000h | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range -10 to 20 % | ||
Ripple and Noise 75mV Pk-Pk | ||
Number of Pins 7 | ||
Isolation Voltage 3000V | ||
Maximum Output Power 10W | ||
Package Type 1 x 1 in | ||
Depth 9.9mm | ||
Length 25.4mm | ||
Standards/Approvals EN 45545-2, EN 50155, EN 61373, IEC 62368-1, UL 62368-1 | ||
Width 20.32mm | ||
Series THN 10UIR | ||
Weight 16.1g | ||
Better World Claim Concentrated or Compact Solution | ||
Better World Product Yes | ||
Maximum Operating Temperature 95°C | ||
Efficiency 88% | ||
Minimum Operating Temperature -40°C | ||
