TRACOPOWER THN 10UIR DC/DC Converter, 5.1V dc/ 2000 mA, 160V Input, 9V Input 10 W, PCB, 95 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 608-885
- Mfr. Part No.:
- THN 10-3611UIR
- Brand:
- TRACOPOWER
Subtotal (1 unit)*
£30.95
(exc. VAT)
£37.14
(inc. VAT)
Units | Per unit |
|---|---|
| 1 + | £30.95 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 608-885
- Mfr. Part No.:
- THN 10-3611UIR
- Brand:
- TRACOPOWER
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 5.1V dc | |
| Minimum Input Voltage | 9V | |
| Maximum Input Voltage | 160V | |
| Output Current 1 | 2000mA | |
| Mount Type | PCB | |
| Output Voltage 2 | -5V dc | |
| Input Ratio | 12:1 | |
| Number of Outputs | 1 | |
| MTBF | 1928000h | |
| Ripple and Noise | 75mV Pk-Pk | |
| Output Voltage Adjustment Range | -10 to 20 % | |
| Number of Pins | 7 | |
| Isolation Voltage | 3000V | |
| Maximum Output Power | 10W | |
| Package Type | Metal case | |
| Depth | 9.9mm | |
| Series | THN 10UIR | |
| Standards/Approvals | EN 50155, EN 61373, IEC 62368-1, UL 62368-1, EN 45545-2 | |
| Width | 25.4mm | |
| Weight | 16.1g | |
| Length | 25.4mm | |
| Better World Product | Yes | |
| Better World Claim | Concentrated or Compact Solution | |
| Maximum Operating Temperature | 95°C | |
| Efficiency | 86% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type DC/DC Converter | ||
Output Voltage 1 5.1V dc | ||
Minimum Input Voltage 9V | ||
Maximum Input Voltage 160V | ||
Output Current 1 2000mA | ||
Mount Type PCB | ||
Output Voltage 2 -5V dc | ||
Input Ratio 12:1 | ||
Number of Outputs 1 | ||
MTBF 1928000h | ||
Ripple and Noise 75mV Pk-Pk | ||
Output Voltage Adjustment Range -10 to 20 % | ||
Number of Pins 7 | ||
Isolation Voltage 3000V | ||
Maximum Output Power 10W | ||
Package Type Metal case | ||
Depth 9.9mm | ||
Series THN 10UIR | ||
Standards/Approvals EN 50155, EN 61373, IEC 62368-1, UL 62368-1, EN 45545-2 | ||
Width 25.4mm | ||
Weight 16.1g | ||
Length 25.4mm | ||
Better World Product Yes | ||
Better World Claim Concentrated or Compact Solution | ||
Maximum Operating Temperature 95°C | ||
Efficiency 86% | ||
Minimum Operating Temperature -40°C | ||
