MEAN WELL N7812 DC-DC Converter, 13V dc/ 0 → 2000mA Output, 16 → 32 V dc Input, 3.6 → 30W, Through
- RS Stock No.:
- 590-685
- Mfr. Part No.:
- N7812-2CH
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£4.23
(exc. VAT)
£5.08
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 13 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £4.23 |
*price indicative
- RS Stock No.:
- 590-685
- Mfr. Part No.:
- N7812-2CH
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | MEAN WELL | |
Output Voltage | 13V dc | |
Input Voltage Range | 16 → 32 V dc | |
Power Rating | 3.6 → 30W | |
Input Voltage Nominal | 24 V dc | |
Output Current | 0 → 2000mA | |
Mounting Type | Through Hole | |
Series | N7812 | |
Minimum Temperature | -40°C | |
Maximum Temperature | +85°C | |
Select all | ||
---|---|---|
Brand MEAN WELL | ||
Output Voltage 13V dc | ||
Input Voltage Range 16 → 32 V dc | ||
Power Rating 3.6 → 30W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 0 → 2000mA | ||
Mounting Type Through Hole | ||
Series N7812 | ||
Minimum Temperature -40°C | ||
Maximum Temperature +85°C | ||
- COO (Country of Origin):
- TW
The MEANWELL Switching Regulators offer the flexibility to select either a positive or negative output voltage depending on the application, deliver high efficiency of up to 96% resulting in low power loss, operate within a wide temperature range from -40°C to +85°C without requiring an additional heat sink, and comply with EN55032 Class B radiated emission standards without the need for external components.
Compact size
Protections include short circuit, overload, and over temperature
Low ripple and noise
3 years warranty
Protections include short circuit, overload, and over temperature
Low ripple and noise
3 years warranty
