MEAN WELL RSD DC/DC Converter, 15V dc/ 1.33 A, 160V dc Input, 160V dc Input 20 W, PCB, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 149-668
- Distrelec Article No.:
- 302-30-070
- Mfr. Part No.:
- RSDW20H-15
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£27.48
(exc. VAT)
£32.98
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 26 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £27.48 |
*price indicative
- RS Stock No.:
- 149-668
- Distrelec Article No.:
- 302-30-070
- Mfr. Part No.:
- RSDW20H-15
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 15V dc | |
| Minimum Input Voltage | 160V dc | |
| Maximum Input Voltage | 160V dc | |
| Output Current 1 | 1.33A | |
| Output Current 2 | 2000mA | |
| Output Voltage 2 | 15V dc | |
| Mount Type | PCB | |
| Number of Outputs | 2 | |
| MTBF | 880kH | |
| Ripple and Noise | 60mV Pk-Pk | |
| Output Voltage Adjustment Range | ±10 % | |
| Isolation Voltage | 3V | |
| Number of Pins | 6 | |
| Maximum Output Power | 20W | |
| Package Type | 2 x 1 in | |
| Width | 25.4mm | |
| Weight | 35g | |
| Standards/Approvals | IEC60571, EN50155, EN61373, EN50121-3-2, EAC TP TC 020/2011, EAC TP TC 004 | |
| Series | RSD | |
| Length | 50.8mm | |
| Depth | 10.2mm | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 90% | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type DC/DC Converter | ||
Output Voltage 1 15V dc | ||
Minimum Input Voltage 160V dc | ||
Maximum Input Voltage 160V dc | ||
Output Current 1 1.33A | ||
Output Current 2 2000mA | ||
Output Voltage 2 15V dc | ||
Mount Type PCB | ||
Number of Outputs 2 | ||
MTBF 880kH | ||
Ripple and Noise 60mV Pk-Pk | ||
Output Voltage Adjustment Range ±10 % | ||
Isolation Voltage 3V | ||
Number of Pins 6 | ||
Maximum Output Power 20W | ||
Package Type 2 x 1 in | ||
Width 25.4mm | ||
Weight 35g | ||
Standards/Approvals IEC60571, EN50155, EN61373, EN50121-3-2, EAC TP TC 020/2011, EAC TP TC 004 | ||
Series RSD | ||
Length 50.8mm | ||
Depth 10.2mm | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
Efficiency 90% | ||
RoHS Status: Exempt
The MEANWELL DC-DC Railway Single Output Converter is a reliable power supply solution designed for transport applications. With an input range of 43-160VDC and an output of 15VDC at 1.33A, this converter offers high efficiency and performance. The 3KVDC I/O isolation ensures safe operation in demanding environments, making it a versatile choice for various industrial applications.
DC-DC Railway Single Output Converter
Input range of 43-160VDC
Output of 15VDC at 1.33A
3KVDC I/O isolation for safety
DIP Through hole package for easy installation
Remote ON/OFF feature for added convenience
Compact and durable design
RoHS Compliant for environmental sustainability
