HARTING 9 Way Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Threaded Inserts, Boardlocks
- RS Stock No.:
- 923-5081
- Mfr. Part No.:
- 09661516513
- Brand:
- HARTING
Save 14% when you buy 200 units
Subtotal (1 box of 100 units)*
£340.70
(exc. VAT)
£408.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 100 - 100 | £3.407 | £340.70 |
| 200 + | £2.896 | £289.60 |
*price indicative
- RS Stock No.:
- 923-5081
- Mfr. Part No.:
- 09661516513
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Straight | |
| Mounting Type | Through Hole | |
| Pitch | 2.74mm | |
| Termination Method | Solder | |
| Mounting Hardware | 4-40 UNC Threaded Inserts, Boardlocks | |
| Current Rating | 7.5A | |
| Housing Material | Steel | |
| Length | 31.2mm | |
| Width | 12.4mm | |
| Depth | 12.5mm | |
| Contact Plating | Gold | |
| Contact Material | Copper Alloy | |
| Dimensions | 31.2 x 12.4 x 12.5mm | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Straight | ||
Mounting Type Through Hole | ||
Pitch 2.74mm | ||
Termination Method Solder | ||
Mounting Hardware 4-40 UNC Threaded Inserts, Boardlocks | ||
Current Rating 7.5A | ||
Housing Material Steel | ||
Length 31.2mm | ||
Width 12.4mm | ||
Depth 12.5mm | ||
Contact Plating Gold | ||
Contact Material Copper Alloy | ||
Dimensions 31.2 x 12.4 x 12.5mm | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- RO
D-Sub Stamped solder pins, straight with grounding board locks
Standard subminiature D connectors
Stamped contacts
Performance level 2
Metal shell
4-40 UNC
Stamped contacts
Performance level 2
Metal shell
4-40 UNC
Standards
IEC 60 807
