HARTING D-Sub Standard 25 Way Right Angle Through Hole D-sub Connector Socket, 2.76mm Pitch, with Boardlocks, M3
- RS Stock No.:
- 740-7247
- Mfr. Part No.:
- 09663526611
- Brand:
- HARTING
Subtotal (1 unit)*
£3.28
(exc. VAT)
£3.94
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 3 unit(s), ready to ship
Units | Per unit |
|---|---|
| 1 + | £3.28 |
*price indicative
- RS Stock No.:
- 740-7247
- Mfr. Part No.:
- 09663526611
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 25 | |
| Gender | Female | |
| Body Orientation | Right Angle | |
| Mounting Type | Through Hole | |
| Pitch | 2.76mm | |
| Mounting Hardware | Boardlocks, M3 Threaded Inserts | |
| Termination Method | Solder | |
| Current Rating | 6.5A | |
| Housing Material | Steel | |
| Length | 53.2mm | |
| Width | 15.0mm | |
| Depth | 12.5mm | |
| Dimensions | 53.2 x 15 x 12.5mm | |
| Series | D-Sub Standard | |
| Contact Material | Copper Alloy | |
| Minimum Operating Temperature | -55.0°C | |
| Maximum Operating Temperature | +125°C | |
| Series Number | 966 | |
Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 25 | ||
Gender Female | ||
Body Orientation Right Angle | ||
Mounting Type Through Hole | ||
Pitch 2.76mm | ||
Mounting Hardware Boardlocks, M3 Threaded Inserts | ||
Termination Method Solder | ||
Current Rating 6.5A | ||
Housing Material Steel | ||
Length 53.2mm | ||
Width 15.0mm | ||
Depth 12.5mm | ||
Dimensions 53.2 x 15 x 12.5mm | ||
Series D-Sub Standard | ||
Contact Material Copper Alloy | ||
Minimum Operating Temperature -55.0°C | ||
Maximum Operating Temperature +125°C | ||
Series Number 966 | ||
- COO (Country of Origin):
- CH
Harting 2.54mm DIN 41652 Standard D-Sub Connectors, Stamped Pins, Board Locks
A concise range of stamped pin D-sub connectors, ideal for cable to board applications such as communication and data interfacing. These durable D connectors have a good mating cycle and feature plated steel housings along with copper alloy contacts.
Standard subminiature D connectors
Stamped contacts
Performance level 2
Metal shell
4-40 UNC
Stamped contacts
Performance level 2
Metal shell
4-40 UNC
Standards
IEC 60 807
