Harting D-Sub Standard 9 Way Right Angle SMT D-sub Connector Socket, 2.76mm Pitch, with 4-40 UNC Female Screwlocks,
- RS Stock No.:
- 692-6071
- Mfr. Part No.:
- 09551566620741
- Brand:
- HARTING
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 692-6071
- Mfr. Part No.:
- 09551566620741
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Right Angle | |
| Mounting Type | Surface Mount | |
| Pitch | 2.76mm | |
| Mounting Hardware | 4-40 UNC Female Screwlocks, Boardlocks | |
| Termination Method | Solder | |
| Current Rating | 5.0A | |
| Housing Material | Liquid Crystal Polymer | |
| Length | 31.0mm | |
| Width | 19.0mm | |
| Depth | 12.7mm | |
| Dimensions | 31 x 19 x 12.7mm | |
| Series | D-Sub Standard | |
| Series Number | 0955 | |
| Maximum Operating Temperature | +260°C | |
Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Right Angle | ||
Mounting Type Surface Mount | ||
Pitch 2.76mm | ||
Mounting Hardware 4-40 UNC Female Screwlocks, Boardlocks | ||
Termination Method Solder | ||
Current Rating 5.0A | ||
Housing Material Liquid Crystal Polymer | ||
Length 31.0mm | ||
Width 19.0mm | ||
Depth 12.7mm | ||
Dimensions 31 x 19 x 12.7mm | ||
Series D-Sub Standard | ||
Series Number 0955 | ||
Maximum Operating Temperature +260°C | ||
- COO (Country of Origin):
- CN
D-Sub Female PCB SMT Low Profile Connectors
Low profile version
Stamped solder pins
Tinned metal shell
Performance level 2
Stamped solder pins
Tinned metal shell
Performance level 2
