Norcomp 180 44 Way Through Hole D-sub Connector Plug, 2.29mm Pitch, with 4-40 Spacer/Board Lock
- RS Stock No.:
- 174-8521
- Mfr. Part No.:
- 180-M44-113R911
- Brand:
- Norcomp
Bulk discount available
Subtotal (1 tray of 20 units)*
£195.30
(exc. VAT)
£234.36
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 960 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 20 - 20 | £9.765 | £195.30 |
| 40 - 80 | £8.867 | £177.34 |
| 100 + | £8.213 | £164.26 |
*price indicative
- RS Stock No.:
- 174-8521
- Mfr. Part No.:
- 180-M44-113R911
- Brand:
- Norcomp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norcomp | |
| Number of Contacts | 44 | |
| Gender | Male | |
| Body Orientation | Straight | |
| Mounting Type | Through Hole | |
| Pitch | 2.29mm | |
| D Connector Type | High Density D-Sub | |
| Termination Method | Solder | |
| Mounting Hardware | 4-40 Spacer/Board Lock | |
| Current Rating | 5.0A | |
| Housing Material | Steel | |
| Voltage Rating | 1.0 kV | |
| Length | 53.05mm | |
| Width | 12.5mm | |
| Depth | 12.1mm | |
| Contact Plating | Gold Flash | |
| Series | 180 | |
| Dimensions | 53.05 x 12.5 x 12.1mm | |
| Contact Material | Brass | |
| Series Number | 180 | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand Norcomp | ||
Number of Contacts 44 | ||
Gender Male | ||
Body Orientation Straight | ||
Mounting Type Through Hole | ||
Pitch 2.29mm | ||
D Connector Type High Density D-Sub | ||
Termination Method Solder | ||
Mounting Hardware 4-40 Spacer/Board Lock | ||
Current Rating 5.0A | ||
Housing Material Steel | ||
Voltage Rating 1.0 kV | ||
Length 53.05mm | ||
Width 12.5mm | ||
Depth 12.1mm | ||
Contact Plating Gold Flash | ||
Series 180 | ||
Dimensions 53.05 x 12.5 x 12.1mm | ||
Contact Material Brass | ||
Series Number 180 | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- TW
Vertical solder d-subs available in 5 industry sizes/positions:
High Density (15, 26, 44, 62, 78).
Approximately 65% more higher density then standard d-sub connectors.
Screw machined contacts offer high reliability.
Metal Shell provides EMI/RFI shielding. Available with 4 clinch-nut options.
Plug shells have indents to provide grounding & additional retention.
Connectors will fit in standard d-sub backshells.
Shell: Steel, Nickel plated
Insulator: PA6T, (260°C process temp)
Machined contacts: Brass, Gold Flash Plated
High Density (15, 26, 44, 62, 78).
Approximately 65% more higher density then standard d-sub connectors.
Screw machined contacts offer high reliability.
Metal Shell provides EMI/RFI shielding. Available with 4 clinch-nut options.
Plug shells have indents to provide grounding & additional retention.
Connectors will fit in standard d-sub backshells.
Shell: Steel, Nickel plated
Insulator: PA6T, (260°C process temp)
Machined contacts: Brass, Gold Flash Plated
