Norcomp 180 44 Way Panel Mount D-sub Connector Socket, 2.286mm Pitch
- RS Stock No.:
- 174-8522
- Mfr. Part No.:
- 180-M44-203L001
- Brand:
- Norcomp
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 174-8522
- Mfr. Part No.:
- 180-M44-203L001
- Brand:
- Norcomp
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norcomp | |
| Number of Contacts | 44 | |
| Gender | Female | |
| Body Orientation | Straight | |
| Mounting Type | Panel Mount | |
| Pitch | 2.286mm | |
| D Connector Type | High Density D-Sub | |
| Termination Method | Solder | |
| Current Rating | 5.0A | |
| Housing Material | Steel | |
| Voltage Rating | 1.0 kV | |
| Length | 38.4mm | |
| Width | 12.5mm | |
| Depth | 11.7mm | |
| Dimensions | 38.4 x 12.5 x 11.7mm | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold Flash | |
| Series | 180 | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand Norcomp | ||
Number of Contacts 44 | ||
Gender Female | ||
Body Orientation Straight | ||
Mounting Type Panel Mount | ||
Pitch 2.286mm | ||
D Connector Type High Density D-Sub | ||
Termination Method Solder | ||
Current Rating 5.0A | ||
Housing Material Steel | ||
Voltage Rating 1.0 kV | ||
Length 38.4mm | ||
Width 12.5mm | ||
Depth 11.7mm | ||
Dimensions 38.4 x 12.5 x 11.7mm | ||
Contact Material Copper Alloy | ||
Contact Plating Gold Flash | ||
Series 180 | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
