Norcomp 180 44 Way Panel Mount D-sub Connector Plug, 2.29mm Pitch
- RS Stock No.:
- 174-8511
- Mfr. Part No.:
- 180-044-103L001
- Brand:
- Norcomp
Bulk discount available
Subtotal (1 tray of 50 units)*
£206.85
(exc. VAT)
£248.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 300 unit(s) shipping from 14 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 50 - 50 | £4.137 | £206.85 |
| 100 - 200 | £3.872 | £193.60 |
| 250 + | £3.678 | £183.90 |
*price indicative
- RS Stock No.:
- 174-8511
- Mfr. Part No.:
- 180-044-103L001
- Brand:
- Norcomp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norcomp | |
| Number of Contacts | 44 | |
| Gender | Male | |
| Body Orientation | Straight | |
| Mounting Type | Panel Mount | |
| Pitch | 2.29mm | |
| D Connector Type | High Density D-Sub | |
| Termination Method | Solder | |
| Current Rating | 5.0A | |
| Housing Material | Steel | |
| Voltage Rating | 500.0 V | |
| Length | 53.0mm | |
| Width | 12.6mm | |
| Depth | 12.0mm | |
| Contact Plating | Gold Flash | |
| Contact Material | Brass | |
| Dimensions | 53 x 12.6 x 12mm | |
| Series | 180 | |
| Maximum Operating Temperature | +100°C | |
| Minimum Operating Temperature | -50.0°C | |
Select all | ||
|---|---|---|
Brand Norcomp | ||
Number of Contacts 44 | ||
Gender Male | ||
Body Orientation Straight | ||
Mounting Type Panel Mount | ||
Pitch 2.29mm | ||
D Connector Type High Density D-Sub | ||
Termination Method Solder | ||
Current Rating 5.0A | ||
Housing Material Steel | ||
Voltage Rating 500.0 V | ||
Length 53.0mm | ||
Width 12.6mm | ||
Depth 12.0mm | ||
Contact Plating Gold Flash | ||
Contact Material Brass | ||
Dimensions 53 x 12.6 x 12mm | ||
Series 180 | ||
Maximum Operating Temperature +100°C | ||
Minimum Operating Temperature -50.0°C | ||
- COO (Country of Origin):
- TW
Solder cup d-subs available in 5 industry sizes/positions
High Density (15 pin, 26 pin, 44 pin, 62 pin, 78 pin).
Approximately 65% higher density than standard D-Sub connectors.
Low cost & high performance stamped contacts.
Metal shell provides EMI/RFI shielding.
Plug shells have indents to provide grounding and additional retention.
Connectors will fit in standard d-sub backshells.
Shell: Steel, Tin or Nickel Plating
Insulator: Glass-filled thermoplastic. (230°C process temp)
Contacts: Brass, Gold Flash Plated (Entire Contact)
High Density (15 pin, 26 pin, 44 pin, 62 pin, 78 pin).
Approximately 65% higher density than standard D-Sub connectors.
Low cost & high performance stamped contacts.
Metal shell provides EMI/RFI shielding.
Plug shells have indents to provide grounding and additional retention.
Connectors will fit in standard d-sub backshells.
Shell: Steel, Tin or Nickel Plating
Insulator: Glass-filled thermoplastic. (230°C process temp)
Contacts: Brass, Gold Flash Plated (Entire Contact)
