Harting D-Sub 9 Way Right Angle Through Hole D-sub Connector Plug, 2.77mm Pitch, with 4-40 UNC Screwlocks
- RS Stock No.:
- 139-3693
- Mfr. Part No.:
- 09681635813
- Brand:
- HARTING
- RS Stock No.:
- 139-3693
- Mfr. Part No.:
- 09681635813
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 9 | |
| Gender | Male | |
| Body Orientation | Right Angle | |
| Mounting Type | Through Hole | |
| Pitch | 2.77 mm, 2.84mm | |
| D Connector Type | Standard D-Sub | |
| Mounting Hardware | 4-40 UNC Screwlocks | |
| Termination Method | Solder | |
| Current Rating | 6.5A | |
| Mixed Contact Layout | 9W2 | |
| Housing Material | Glass Fibre Reinforced Thermoplastic | |
| Length | 30.9mm | |
| Width | 12.55mm | |
| Depth | 18.2mm | |
| Contact Material | Copper Alloy | |
| Series | D-Sub | |
| Dimensions | 30.9 x 12.55 x 18.2mm | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
| Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 9 | ||
Gender Male | ||
Body Orientation Right Angle | ||
Mounting Type Through Hole | ||
Pitch 2.77 mm, 2.84mm | ||
D Connector Type Standard D-Sub | ||
Mounting Hardware 4-40 UNC Screwlocks | ||
Termination Method Solder | ||
Current Rating 6.5A | ||
Mixed Contact Layout 9W2 | ||
Housing Material Glass Fibre Reinforced Thermoplastic | ||
Length 30.9mm | ||
Width 12.55mm | ||
Depth 18.2mm | ||
Contact Material Copper Alloy | ||
Series D-Sub | ||
Dimensions 30.9 x 12.55 x 18.2mm | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- CN
Harting 9, 15 and 25 way Solder D-Sub Miniature Plugs- U.S Footprint
From Harting, a range of solder D-Sub miniature connectors with stamped and angled male contacts. The U.S footprint plugs have copper alloy contacts in a robust metal shell with extra grounding pin. Secured in the panel with a fixing flange and 4 to 40 UNC screw lock. The D-Sub miniature connectors in this range have a performance level S2.
Features and Benefits
• Robust metal shell
• 6.5A rated current
• Wave solder termination
• Extra grounding pin
• U.S footprint
• Stamped angled contacts
• 6.5A rated current
• Wave solder termination
• Extra grounding pin
• U.S footprint
• Stamped angled contacts
D-Sub Connectors - Harting
