Amphenol Communications Solutions 9 Way Plug-In Mount D-sub Connector, with Screw
- RS Stock No.:
- 137-2548
- Mfr. Part No.:
- 8655MH0901LF
- Brand:
- Amphenol Communications Solutions
Subtotal (1 pack of 80 units)*
£444.48
(exc. VAT)
£533.36
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 80 + | £5.556 | £444.48 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£8.29
(exc. VAT)
£9.95
(inc. VAT)
- RS Stock No.:
- 137-2548
- Mfr. Part No.:
- 8655MH0901LF
- Brand:
- Amphenol Communications Solutions
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Communications Solutions | |
| Number of Contacts | 9 | |
| Body Orientation | Straight | |
| Mounting Type | Plug-In Mount | |
| D Connector Type | Standard D-Sub | |
| D-Sub Shell Size | E | |
| Termination Method | Solder | |
| Mounting Hardware | Screw | |
| Mixed Contact Layout | 9W2 | |
| Housing Material | Metal | |
| Length | 34.4mm | |
| Width | 14.7mm | |
| Depth | 55.0mm | |
| Contact Plating | Gold over Nickel | |
| Dimensions | 34.4 x 14.7 x 55mm | |
| Minimum Operating Temperature | -55.0°C | |
| Maximum Operating Temperature | +125°C | |
Select all | ||
|---|---|---|
Brand Amphenol Communications Solutions | ||
Number of Contacts 9 | ||
Body Orientation Straight | ||
Mounting Type Plug-In Mount | ||
D Connector Type Standard D-Sub | ||
D-Sub Shell Size E | ||
Termination Method Solder | ||
Mounting Hardware Screw | ||
Mixed Contact Layout 9W2 | ||
Housing Material Metal | ||
Length 34.4mm | ||
Width 14.7mm | ||
Depth 55.0mm | ||
Contact Plating Gold over Nickel | ||
Dimensions 34.4 x 14.7 x 55mm | ||
Minimum Operating Temperature -55.0°C | ||
Maximum Operating Temperature +125°C | ||
- COO (Country of Origin):
- FR
Amphenol FCI's D-Subminiature (D-Sub) connectors are part of industry standard and are one of the most popular Input/Output interconnects, addressing a wide variety of applications including telecommunications, industrial and medical.
Prevents accidental mismating
Metal hoods available in straight and angled terminations for EMI/RFI shielding
Dust caps available in metal and plastic versions
Locking screws comes with UNC 4-40 and M3 thread options
Hoods available in different orientations and locking options
Metal hoods available in straight and angled terminations for EMI/RFI shielding
Dust caps available in metal and plastic versions
Locking screws comes with UNC 4-40 and M3 thread options
Hoods available in different orientations and locking options
