L-Com C&P 15 Way Straight 2.77 mm Pitch Through Hole D-Sub Connector, with Screw Lock, Board Lock Male
- RS Stock No.:
- 671-767
- Mfr. Part No.:
- C&P15M
- Brand:
- L-Com
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£2.71
(exc. VAT)
£3.25
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 25 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £2.71 |
| 10 + | £2.48 |
*price indicative
- RS Stock No.:
- 671-767
- Mfr. Part No.:
- C&P15M
- Brand:
- L-Com
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | L-Com | |
| Number of Contacts | 15 | |
| Product Type | D-Sub Connector | |
| Orientation | Straight | |
| Mount Type | Through Hole | |
| Connector Gender | Male | |
| Mounting Hardware | Screw Lock, Board Lock | |
| Contact Gender | Male | |
| Standards/Approvals | RoHS Compliant | |
| Series | C&P | |
| Contact Plating | Tin, Nickel Plated | |
| Contact Material | Gold Plated | |
| Pitch | 2.77mm | |
| Select all | ||
|---|---|---|
Brand L-Com | ||
Number of Contacts 15 | ||
Product Type D-Sub Connector | ||
Orientation Straight | ||
Mount Type Through Hole | ||
Connector Gender Male | ||
Mounting Hardware Screw Lock, Board Lock | ||
Contact Gender Male | ||
Standards/Approvals RoHS Compliant | ||
Series C&P | ||
Contact Plating Tin, Nickel Plated | ||
Contact Material Gold Plated | ||
Pitch 2.77mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
The L-Com D-Sub Insertion Type D-Sub Connector DB15 Male is used to interface electronic devices through a 15-pin configuration in RS232 and VGA applications. The connector features a straight body orientation for easy PCB mounting and soldering. It is commonly used in industrial control systems, communication setups, and embedded hardware.
Connector type DB15 Male with 15 pins
Body orientation straight for PCB insertion
Solder type termination for secure electrical contact
