Wurth Elektronik 24 MHz Crystal ±20.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5mm
- RS Stock No.:
- 197-623
- Mfr. Part No.:
- 830058124
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 10 units)*
£3.95
(exc. VAT)
£4.74
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2,980 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.395 | £3.95 |
| 100 - 240 | £0.375 | £3.75 |
| 250 - 490 | £0.347 | £3.47 |
| 500 - 990 | £0.32 | £3.20 |
| 1000 + | £0.309 | £3.09 |
*price indicative
- RS Stock No.:
- 197-623
- Mfr. Part No.:
- 830058124
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 24MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 18pF | |
| Packaging | Tape & Reel | |
| Package Type | SMT | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±20.00 ppm | |
| Minimum Operating Temperature | -40.00°C | |
| Frequency Stability | ±30 ppm | |
| Maximum Operating Temperature | 85.00°C | |
| Series Resistance | 50Ω | |
| Series | CFPX-180 | |
| Standards/Approvals | MIL-STD-202F | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 24MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 18pF | ||
Packaging Tape & Reel | ||
Package Type SMT | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5mm | ||
Height 2.5mm | ||
Frequency Tolerance ±20.00 ppm | ||
Minimum Operating Temperature -40.00°C | ||
Frequency Stability ±30 ppm | ||
Maximum Operating Temperature 85.00°C | ||
Series Resistance 50Ω | ||
Series CFPX-180 | ||
Standards/Approvals MIL-STD-202F | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 3.2 x 2.5mm SMD quartz crystal is expertly designed to deliver exceptional performance in various electronic applications. Encased in a robust ceramic package with a hermetically sealed metal lid, it offers enhanced durability and reliability. With a remarkable frequency of 24.0MHz and impressive tolerance levels, this crystal demonstrates superior performance for oscillation and timing applications. Additionally, its compliance with RoHS standards showcases a commitment to environmental responsibility, making it a responsible choice for modern electronics.
Designed with a hermetically sealed metal LID for enhanced reliability
Provides excellent frequency stability across various temperature ranges
Engineered for minimal ageing effects which ensuring long lasting performance
Adheres to strict military specifications for shock and vibration resistance
Compact form factor Ideal for space constrained applications
Suitable for a wide array of electronic devices from communications to consumer products
