Wurth Elektronik 24 MHz Crystal ±20.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5mm
- RS Stock No.:
- 197-607
- Mfr. Part No.:
- 830064703
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 3000 units)*
£1,194.00
(exc. VAT)
£1,434.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.398 | £1,194.00 |
*price indicative
- RS Stock No.:
- 197-607
- Mfr. Part No.:
- 830064703
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Crystal | |
| Standard Frequency | 24MHz | |
| Mount Type | Surface Mount | |
| Load Capacitance | 18pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±20.00 ppm | |
| Frequency Stability | ±50 ppm | |
| Minimum Operating Temperature | -40.00°C | |
| Series Resistance | 50Ω | |
| Maximum Operating Temperature | 85.00°C | |
| Standards/Approvals | RoHS, REACH, MIL-STD-202F | |
| Series | CFPX-180 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Crystal | ||
Standard Frequency 24MHz | ||
Mount Type Surface Mount | ||
Load Capacitance 18pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5mm | ||
Height 2.5mm | ||
Frequency Tolerance ±20.00 ppm | ||
Frequency Stability ±50 ppm | ||
Minimum Operating Temperature -40.00°C | ||
Series Resistance 50Ω | ||
Maximum Operating Temperature 85.00°C | ||
Standards/Approvals RoHS, REACH, MIL-STD-202F | ||
Series CFPX-180 | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 3.2 x 2.5mm SMD crystal is designed for reliability and precision in demanding applications. Housed in a robust ceramic package with a seam sealed metal lid, this quartz crystal offers exceptional hermetic sealing to ensure optimal performance in a variety of environmental conditions. Its fundamental overtone order and impressive frequency stability make it an Ideal choice for circuits requiring precise timing.
Designed to meet stringent frequency stability requirements
RoHS compliant supporting environmentally friendly manufacturing
Offers a robust load capacitance design for improved circuit performance
Minimal ageing effects ensure dependable performance year after year
Vibration and shock tested to withstand demanding operational environments
Compact size facilitates easy integration into space constrained applications
