Microchip Complex Programmable Logic Device ATF15xx EEPROM 64 Cells, 32 I/O, 7.5 ns 10 Labs, In System Programmability
- RS Stock No.:
- 177-3643P
- Mfr. Part No.:
- ATF1504ASL-25AU44
- Brand:
- Microchip
Subtotal 2 units (supplied in a tray)*
£8.76
(exc. VAT)
£10.52
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 160 unit(s) shipping from 08 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 2 + | £4.38 |
*price indicative
- RS Stock No.:
- 177-3643P
- Mfr. Part No.:
- ATF1504ASL-25AU44
- Brand:
- Microchip
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Microchip | |
| Product Type | Complex Programmable Logic Device | |
| Series | ATF15xx | |
| Number of Macro Cells | 64 | |
| Number of User I/Os | 32 | |
| Memory Type | EEPROM | |
| Maximum Propagation Delay Time | 7.5ns | |
| Number of Logic Blocks/Elements | 10 | |
| In System Programmability | Yes | |
| Mount Type | Surface | |
| Package Type | TQFP | |
| Minimum Supply Voltage | 3V | |
| Minimum Operating Temperature | -40°C | |
| Pin Count | 44 | |
| Maximum Operating Temperature | 85°C | |
| Maximum Supply Voltage | 3.6V | |
| Individual Output Enable Control | Yes | |
| Length | 10.1mm | |
| Standards/Approvals | No | |
| Height | 1.05mm | |
| Maximum Operating Frequency | 125MHz | |
| Re-programmability Support | Yes | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Microchip | ||
Product Type Complex Programmable Logic Device | ||
Series ATF15xx | ||
Number of Macro Cells 64 | ||
Number of User I/Os 32 | ||
Memory Type EEPROM | ||
Maximum Propagation Delay Time 7.5ns | ||
Number of Logic Blocks/Elements 10 | ||
In System Programmability Yes | ||
Mount Type Surface | ||
Package Type TQFP | ||
Minimum Supply Voltage 3V | ||
Minimum Operating Temperature -40°C | ||
Pin Count 44 | ||
Maximum Operating Temperature 85°C | ||
Maximum Supply Voltage 3.6V | ||
Individual Output Enable Control Yes | ||
Length 10.1mm | ||
Standards/Approvals No | ||
Height 1.05mm | ||
Maximum Operating Frequency 125MHz | ||
Re-programmability Support Yes | ||
Automotive Standard No | ||
- COO (Country of Origin):
- US
The Atmel ®ATF1504AS(L) is a high-performance, high-density Complex Programmable Logic Device (CPLD) which utilizes the Atmel proven electrically-erasable memory technology. With 64 logic macrocells and up to 68 inputs, it easily integrates logic from several TTL, SSI, MSI, LSI, and classic PLDs.
High-density, High-performance, Electrically-erasable Complex Programmable
Logic Device
64 Macrocells
5 Product Terms per Macrocell, Expandable up to 40 per Macrocell
44, 84, 100 Pins
7.5ns Maximum Pin-to-pin Delay
Registered Operation up to 125MHz
Enhanced Routing Resources
In-System Programmability (ISP) via JTAG
Flexible Logic Macrocell
D/T/Latch Configurable Flip-flops
Global and Individual Register Control Signals
Global and Individual Output Enable
Programmable Output Slew Rate
