Microchip ATF1504AS-10JU84, CPLD ATF1504AS EEPROM 64 Cells, 64 I/O, 4 Labs, 10ns, ISP, 84-Pin PLCC

  • RS Stock No. 171-7831
  • Mfr. Part No. ATF1504AS-10JU84
  • Brand Microchip
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Microchip Technology CPLD

The Microchip Technology ATF1504AS family, PLCC package, surface mount, 84-pin, high performance, a high-density complex programmable logic device (CPLD) is an electrically erasable device. It has a voltage rating between 3.3V and 5V. The (CPLD) is designed with 64 logic macrocells and up to 68 inputs. This device easily integrates logic from several TTL, SSI, MSI, LSI and classic PLDs.

Features and Benefits

• 68 bidirectional I/O pins and four dedicated input pins depending on the type of device package selected
• Advanced EE technology
• Advanced power management
• D/T/Latch configurable flip flops
• EEPROM memory type
• Green (Pb/Halide-free) package options
• In-system programmability (ISP) via JTAG
• Integrated power-on reset and brown-out reset
• JTAG boundary scan testing
• Operating frequency is 125MHz
• Operating temperature ranges between -40°C and 85°C
• Propagation delay is 10ns
• Security fuse feature
• Three global clock pins

Applications

• Digital designs
• Electronic product designers

Specifications
Attribute Value
Family Name ATF1504AS
Number of Macro Cells 64
Number of User I/Os 64
Memory Type EEPROM
Number of Logic Blocks/Elements 4
In System Programmability In System
Mounting Type Surface Mount
Package Type PLCC
Pin Count 84
Propagation Delay 10ns
Individual Output Enable Control Yes
Dimensions 29.41 x 29.41 x 4.06mm
Height 4.06mm
Length 29.41mm
Width 29.41mm
Minimum Operating Supply Voltage 4.5 V
Propagation Delay Test Condition 35pF
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +85 °C
Maximum Operating Supply Voltage 5.5 V
105 In stock for FREE next working day delivery
Price Each (In a Pack of 5)
£ 3.406
(exc. VAT)
£ 4.087
(inc. VAT)
Units
Per unit
Per Pack*
5 - 5
£3.406
£17.03
10 - 20
£3.202
£16.01
25 - 95
£3.112
£15.56
100 +
£3.066
£15.33
*price indicative
