Lapp ÖLFLEX CONTROL TM Control Cable, 2 Cores, 1.5 mm², YY, Unscreened, 50m, Grey Thermoplastic Polymer Sheath, 15 AWG
- RS Stock No.:
- 807-9635
- Mfr. Part No.:
- 281602
- Brand:
- Lapp
Subtotal (1 reel of 50 metres)*
£184.04
(exc. VAT)
£220.85
(inc. VAT)
FREE delivery for orders over £50.00
- 1 unit(s) shipping from 07 November 2025
- Plus 6 unit(s) shipping from 14 November 2025
- Plus 999,999,992 unit(s) shipping from 09 January 2026
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £184.04 | £3.681 |
*price indicative
- RS Stock No.:
- 807-9635
- Mfr. Part No.:
- 281602
- Brand:
- Lapp
Select all | Attribute | Value |
---|---|---|
Brand | Lapp | |
Series | ÖLFLEX CONTROL TM | |
Number of Cores | 2 | |
Cross Sectional Area | 1.5 mm² | |
American Wire Gauge | 15 AWG | |
Conductor Material | Bare Copper | |
Sheath Material | Thermoplastic Polymer | |
Control Cable Type | YY | |
Sheath Colour | Grey | |
Screen Type | Unscreened | |
Screened/Unscreened | Unscreened | |
Minimum Bend Radius | 5 x Diameter | |
Length | 50m | |
Outer Diameter | 7.3mm | |
Voltage Rating | 600 V | |
Standards Met | CE, CSA, UL | |
Maximum Operating Temperature | +90°C | |
Fire Behaviour | Flame Retardant | |
Insulation Material | PVC | |
Drain Wire | Yes | |
Cable Shape | Multicore | |
Minimum Operating Temperature | -40°C | |
Oil Resistant | Yes | |
Select all | ||
---|---|---|
Brand Lapp | ||
Series ÖLFLEX CONTROL TM | ||
Number of Cores 2 | ||
Cross Sectional Area 1.5 mm² | ||
American Wire Gauge 15 AWG | ||
Conductor Material Bare Copper | ||
Sheath Material Thermoplastic Polymer | ||
Control Cable Type YY | ||
Sheath Colour Grey | ||
Screen Type Unscreened | ||
Screened/Unscreened Unscreened | ||
Minimum Bend Radius 5 x Diameter | ||
Length 50m | ||
Outer Diameter 7.3mm | ||
Voltage Rating 600 V | ||
Standards Met CE, CSA, UL | ||
Maximum Operating Temperature +90°C | ||
Fire Behaviour Flame Retardant | ||
Insulation Material PVC | ||
Drain Wire Yes | ||
Cable Shape Multicore | ||
Minimum Operating Temperature -40°C | ||
Oil Resistant Yes | ||
- COO (Country of Origin):
- DE
LAPP ÖLFLEX CONTROL TM Series Control Cable, 2 Cores, 1.5 mm² Cross Sectional Area - 281602
Features & Benefits
• Flame-retardant properties provide added safety for installations
• Unscreened configuration simplifies installation without compromising effectiveness
• PVC insulation ensures robust protection against environmental factors
Applications
• Suitable for industrial machinery requiring a flexible control approach
• Effective in cable tray sections for direct burial
• Applicable in unprotected environments up to 600V for safe operations
What are the temperature limits for safe operation with this cable?
How does the oil resistance enhance performance in demanding conditions?
What installation situations are ideal for this type of cable?
How does the flame-retardant feature benefit safety?
