Alpha Wire Ecogen Ecoflex Control Cable, 4 Cores, 0.81 mm², ECO, Unscreened, 30m, Grey mPPE Sheath, 18 AWG

RS Stock No.:: 787-1880
Mfr. Part No.:: 79012 SL005
Brand:: Alpha Wire

Alpha Wire Ecogen Ecoflex Control Cable, 4 Cores, 0.81 mm², ECO, Unscreened, 30m, Grey mPPE Sheath, 18 AWG

Subtotal (1 reel of 31 metres)*

£454.34

(exc. VAT)

£545.21

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

2 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	£454.34	£14.656

*price indicative

Alternative

This product is not currently available. Here is our alternative recommendation.

Alpha Wire Ecogen Ecoflex Control Cable, 2 Cores, 0.81 mm², ECO, Screened, 30m, Grey mPPE Sheath, 18 AWG

RS Stock No.: 787-1916

1 Reel of 31 Metre(s)

£568.91

(exc. VAT)

£682.69

(inc. VAT)

RS Stock No.:: 787-1880
Mfr. Part No.:: 79012 SL005
Brand:: Alpha Wire

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Alpha Wire
	Series	Ecogen Ecoflex
	Number of Cores	4
	Cross Sectional Area	0.81 mm²
	American Wire Gauge	18 AWG
	Conductor Material	Tinned Copper
	Sheath Material	mPPE
	Control Cable Type	ECO
	Sheath Colour	Grey
	Screen Type	Unscreened
	Screened/Unscreened	Unscreened
	Length	30m
	Outer Diameter	5.99mm
	Minimum Bend Radius	5 x Diameter
	Voltage Rating	600 V
	Standards Met	CE, CSA, UL
	Fire Behaviour	Halogen Free
	Maximum Operating Temperature	+105°C
	Minimum Operating Temperature	-40°C
	Core Strands	16/0.25 mm
	Drain Wire	No
	Insulation Material	MPPE

	Select all
	Brand Alpha Wire
	Series Ecogen Ecoflex
	Number of Cores 4
	Cross Sectional Area 0.81 mm²
	American Wire Gauge 18 AWG
	Conductor Material Tinned Copper
	Sheath Material mPPE
	Control Cable Type ECO
	Sheath Colour Grey
	Screen Type Unscreened
	Screened/Unscreened Unscreened
	Length 30m
	Outer Diameter 5.99mm
	Minimum Bend Radius 5 x Diameter
	Voltage Rating 600 V
	Standards Met CE, CSA, UL
	Fire Behaviour Halogen Free
	Maximum Operating Temperature +105°C
	Minimum Operating Temperature -40°C
	Core Strands 16/0.25 mm
	Drain Wire No
	Insulation Material MPPE

Alpha Wire EcoFlex 600 V Continuous Flex Control Cable - Unshielded

The EcoFlex range from Alpha Wire is a moderately flexible compact control cable which is fully recyclable due to its mPPE jacket and insulation construction. This multicore control cable can handle extreme temperatures, contains zero halogens, plus it is smaller and lighter than its PVC equivalent.

Unshielded multi-conductor cables have a small overall diameter and are used in low noise environments.

Features and Benefits

LSZH (Low smoke zero halogens)

Environmentally friendly

Specific gravity: 1.03

Able to handle extreme temperatures as low as -40°C

Finely stranded tinned copper conductors

Excellent abrasion resistance

Smaller, lighter and lower outgassing than PVC control cables

Good mechanical strength

Rated for over 1 million flex life cycles

Available with different core quantities

Temperature Range: -40°C to +105°C (600 V), -40°C to +80°C (300 V)

What is mPPE?

mPPE is a modified polyphenylene ether thermoplastic. Cables with a mPPE sheath have a smaller wall thickness than other cables due to their dielectric properties. The fact that the cables are lighter allows them to be used in many different applications.

mPPE has a lower specific gravity compared to other jacket and insulation materials such as PVC and PE. This combined with the excellent dielectric properties allow the cables to be up to 65% lighter and thinner than conventional cables.

How is the control cable environmentally friendly?

If a cable is not made from materials that contain salt-forming fluorine, bromine, iodine or chlorine then it is defined as halogen-free and flame retardant.

What is halogen-free?

If a cable is not made from materials that contain salt-forming fluorine, bromine, iodine or chlorine then it is defined as halogen-free and flame retardant.

Product Application Information

Control cables are multi-conductor cables used in power applications within the automation and instrumentation industries. Control cables can measure and regulate transmissions of automated processes. These cables have a long flex life in mechanical machines which have constant motion or flexing.

Control cables are also suitable for use in NFPA 79 applications. The purpose of NFPA 79 is to provide safeguards for industrial machinery and to protect operators, equipment, facilities, and work-in-progress from fire and electrical hazards.

Approvals

• UL AWM 21819 (600 V, 105°C) • UL AWM 21492 (300 V, 80°C) • CE • UL VW-1 • CSA AWM I/II A/B FT1 • IEC 60332-2 Flame Behavior • RoHS • REACH • WEEE • ISO 10993-5

EcoFlex Cable, 600 V Unshielded, Multiconductor

Conductors: 4, Black, Red, White, Green
Nominal Diameter: 0.236 inch (5.99 mm)
Jacket Thickness: 0.035 inch (0.89 mm)
Stranding: 16/30
Insulation Thickness: 0.010 (0.25 mm)
18 AWG (0.81 mm²)
Jacket Colour: Slate

EcoCable Range
