Lapp OLFLEX CRANE F Control Cable, 7 Cores, 1.5 mm² CSA 16, Unscreened, Black Rubber Sheath
- RS Stock No.:
- 288-6655
- Mfr. Part No.:
- 41043
- Brand:
- Lapp
Subtotal (1 reel of 50 metres)*
£650.03
(exc. VAT)
£780.04
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £650.03 | £13.001 |
*price indicative
- RS Stock No.:
- 288-6655
- Mfr. Part No.:
- 41043
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Series | OLFLEX CRANE F | |
| Product Type | Control Cable | |
| Number of Cores | 7 | |
| Cross Sectional Area | 1.5 mm² | |
| Conductor Material | Bare Copper | |
| Jacket Material | Rubber | |
| Jacket Colour | Black | |
| Screened/Unscreened | Unscreened | |
| Outside Diameter | 3.25 mm | |
| Voltage | 3000 V | |
| Minimum Operating Temperature | -40°C | |
| Conductor Type | Stranded | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | Cmarked, UKCA marked | |
| American Wire Gauge | 16 | |
| Fire Behaviour | Flame Retardant acc. to IEC 60332-1-2 resp. VDE 0482-332-1-2 | |
| Core Strands | 7 | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Series OLFLEX CRANE F | ||
Product Type Control Cable | ||
Number of Cores 7 | ||
Cross Sectional Area 1.5 mm² | ||
Conductor Material Bare Copper | ||
Jacket Material Rubber | ||
Jacket Colour Black | ||
Screened/Unscreened Unscreened | ||
Outside Diameter 3.25 mm | ||
Voltage 3000 V | ||
Minimum Operating Temperature -40°C | ||
Conductor Type Stranded | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals Cmarked, UKCA marked | ||
American Wire Gauge 16 | ||
Fire Behaviour Flame Retardant acc. to IEC 60332-1-2 resp. VDE 0482-332-1-2 | ||
Core Strands 7 | ||
- COO (Country of Origin):
- RO
The Lapp OLFLEX CRANE F 7G1,5 is a weatherproof power cable for use under harsh environmental conditions. It has 7 cores and 1.5 mm2 cross sectional area of the conductor. It has rubber sheath and is black in colour.
For use in dry, damp or wet areas
Flame retardant
Cable is conform to the low voltage directive
