Lapp H05BQ-F Control Cable, 3 Cores, 0.75 mm² CSA 18, Unscreened, Orange Polyurethane Sheath
- RS Stock No.:
- 288-6609
- Distrelec Article No.:
- 300-49-278
- Mfr. Part No.:
- 13601
- Brand:
- Lapp
Subtotal (1 reel of 50 metres)*
£130.40
(exc. VAT)
£156.48
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £130.40 | £2.608 |
*price indicative
- RS Stock No.:
- 288-6609
- Distrelec Article No.:
- 300-49-278
- Mfr. Part No.:
- 13601
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Product Type | Control Cable | |
| Series | H05BQ-F | |
| Sub Type | Power Cable | |
| Number of Cores | 3 | |
| Cross Sectional Area | 0.75 mm² | |
| Conductor Material | Bare Copper | |
| Jacket Material | Polyurethane | |
| Jacket Colour | Orange | |
| Screened/Unscreened | Unscreened | |
| Outside Diameter | 8.1 mm | |
| Voltage | 3000 V | |
| Conductor Type | Stranded | |
| Minimum Operating Temperature | -50°C | |
| Maximum Operating Temperature | 90°C | |
| Standards/Approvals | UKCA marked, HAR, EAC, Cmarked | |
| American Wire Gauge | 18 | |
| Core Strands | 3 | |
| Distrelec Product Id | 300-49-278 | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Product Type Control Cable | ||
Series H05BQ-F | ||
Sub Type Power Cable | ||
Number of Cores 3 | ||
Cross Sectional Area 0.75 mm² | ||
Conductor Material Bare Copper | ||
Jacket Material Polyurethane | ||
Jacket Colour Orange | ||
Screened/Unscreened Unscreened | ||
Outside Diameter 8.1 mm | ||
Voltage 3000 V | ||
Conductor Type Stranded | ||
Minimum Operating Temperature -50°C | ||
Maximum Operating Temperature 90°C | ||
Standards/Approvals UKCA marked, HAR, EAC, Cmarked | ||
American Wire Gauge 18 | ||
Core Strands 3 | ||
Distrelec Product Id 300-49-278 | ||
- COO (Country of Origin):
- DE
The Lapp OLFLEX 550 P 3G0,75 is a oil-resistant power cable with an isolation of a compound of rubber and an outer sheath of Polyurethane for flexible use and fixed installation for medium abuse. It has 3 cores and 0.75 mm2 cross sectional area of the conductor. It is orange in colour.
For use in dry, damp and wet areas
Cable is conform to the low voltage directive
Cable meets the substance specific requirements of RoHS
