Lapp 45200 Control Cable, 1 Cores, 1.5 mm² CSA 16 AWG, Unscreened, 100 m, Red
- RS Stock No.:
- 283-2206
- Mfr. Part No.:
- 4520041S
- Brand:
- Lapp
Subtotal (1 reel of 150 units)*
£81.87
(exc. VAT)
£98.24
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 7 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per unit* |
|---|---|---|
| 1 + | £81.87 | £0.546 |
*price indicative
- RS Stock No.:
- 283-2206
- Mfr. Part No.:
- 4520041S
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Product Type | Control Cable | |
| Series | 45200 | |
| Sub Type | Single Core | |
| Number of Cores | 1 | |
| Cross Sectional Area | 1.5 mm² | |
| Conductor Material | Bare Copper | |
| Jacket Colour | Red | |
| Screened/Unscreened | Unscreened | |
| Outside Diameter | 3.4 mm | |
| Cable Length | 100m | |
| Voltage | 250 V | |
| Conductor Type | Stranded | |
| Minimum Operating Temperature | -40°C | |
| Standards/Approvals | UN/ECE-R118, HAR-, EAC, Cmarked | |
| Maximum Operating Temperature | 70°C | |
| American Wire Gauge | 16AWG | |
| Core Strands | 1 | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Product Type Control Cable | ||
Series 45200 | ||
Sub Type Single Core | ||
Number of Cores 1 | ||
Cross Sectional Area 1.5 mm² | ||
Conductor Material Bare Copper | ||
Jacket Colour Red | ||
Screened/Unscreened Unscreened | ||
Outside Diameter 3.4 mm | ||
Cable Length 100m | ||
Voltage 250 V | ||
Conductor Type Stranded | ||
Minimum Operating Temperature -40°C | ||
Standards/Approvals UN/ECE-R118, HAR-, EAC, Cmarked | ||
Maximum Operating Temperature 70°C | ||
American Wire Gauge 16AWG | ||
Core Strands 1 | ||
- COO (Country of Origin):
- DE
The Lapp wiring cables feature thermoplastic PVC insulation and are designed for protected, stationary installation inside devices, as well as inside or on lamps. They are suitable for installation inside closed conduits and cable ducting systems, and on or under plaster, but only as part of signal or control circuits.
Flame resistant
Test voltage 2000 V AC
