Lapp 41611 Control Cable, 1 Cores, 35 mm² CSA 2 AWG, Unscreened, 100 m, Black Polyvinyl Chloride Sheath
- RS Stock No.:
- 283-2202
- Mfr. Part No.:
- 4161101
- Brand:
- Lapp
Subtotal (1 reel of 50 metres)*
£556.22
(exc. VAT)
£667.46
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £556.22 | £11.124 |
*price indicative
- RS Stock No.:
- 283-2202
- Mfr. Part No.:
- 4161101
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Product Type | Control Cable | |
| Series | 41611 | |
| Sub Type | Single Core | |
| Number of Cores | 1 | |
| Cross Sectional Area | 35 mm² | |
| Conductor Material | Tin Plated Copper | |
| Jacket Material | Polyvinyl Chloride | |
| Jacket Colour | Black | |
| Screened/Unscreened | Unscreened | |
| Cable Length | 100m | |
| Outside Diameter | 11.3 mm | |
| Voltage | 2500 V | |
| Minimum Operating Temperature | -40°C | |
| Conductor Type | Stranded | |
| Standards/Approvals | CE marked, UKCA marked, CSA certified, EAC Certified, HAR-certified | |
| Maximum Operating Temperature | 70°C | |
| American Wire Gauge | 2AWG | |
| Fire Behaviour | EN | |
| Core Strands | 1 | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Product Type Control Cable | ||
Series 41611 | ||
Sub Type Single Core | ||
Number of Cores 1 | ||
Cross Sectional Area 35 mm² | ||
Conductor Material Tin Plated Copper | ||
Jacket Material Polyvinyl Chloride | ||
Jacket Colour Black | ||
Screened/Unscreened Unscreened | ||
Cable Length 100m | ||
Outside Diameter 11.3 mm | ||
Voltage 2500 V | ||
Minimum Operating Temperature -40°C | ||
Conductor Type Stranded | ||
Standards/Approvals CE marked, UKCA marked, CSA certified, EAC Certified, HAR-certified | ||
Maximum Operating Temperature 70°C | ||
American Wire Gauge 2AWG | ||
Fire Behaviour EN | ||
Core Strands 1 | ||
- COO (Country of Origin):
- DE
The Lapp wiring cables are approved by UL, CSA, and HAR, designed for control cabinet wiring and installation in protective tubes, conforming to UL, Canadian, or European standard specifications. They are particularly suited for wiring in industrial machines in accordance with NFPA 79.
At room temperature they are widely resistant to oils
Insulation special PVC-based compound
