Alpha Wire Alpha Essentials Communication & Control Control Cable, 2 Cores, 0.75 mm² 18 AWG, Screened, 1000 ft, Grey
- RS Stock No.:
- 277-5693
- Mfr. Part No.:
- 3242 SL001
- Brand:
- Alpha Wire
Subtotal (1 reel of 305 metres)*
£1,342.62
(exc. VAT)
£1,611.14
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £1,342.62 | £4.402 |
*price indicative
- RS Stock No.:
- 277-5693
- Mfr. Part No.:
- 3242 SL001
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Series | Alpha Essentials Communication & Control | |
| Product Type | Control Cable | |
| Number of Cores | 2 | |
| Conductor Material | Tin Copper Wire | |
| Jacket Material | Polyvinyl Chloride | |
| Jacket Colour | Grey | |
| Armoured | No | |
| Screened/Unscreened | Screened | |
| Cable Length | 1000ft | |
| Outside Diameter | 0.248 in | |
| Voltage | 600 Vrms | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | EU 2011/65/EU(RoHS2), EU 2015/863/EU (RoHS3), MIL W 16878/Type B/N 105°C / 600 VRMS | |
| Hazardous Area Certification | No | |
| Cable CSA | 0.75 mm² | |
| American Wire Gauge | 18AWG | |
| Core Strands | 19 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Series Alpha Essentials Communication & Control | ||
Product Type Control Cable | ||
Number of Cores 2 | ||
Conductor Material Tin Copper Wire | ||
Jacket Material Polyvinyl Chloride | ||
Jacket Colour Grey | ||
Armoured No | ||
Screened/Unscreened Screened | ||
Cable Length 1000ft | ||
Outside Diameter 0.248 in | ||
Voltage 600 Vrms | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals EU 2011/65/EU(RoHS2), EU 2015/863/EU (RoHS3), MIL W 16878/Type B/N 105°C / 600 VRMS | ||
Hazardous Area Certification No | ||
Cable CSA 0.75 mm² | ||
American Wire Gauge 18AWG | ||
Core Strands 19 | ||
RoHS Status: Exempt
The Alpha Wire multi conductor communication cables provide precise signal transmission in computers and control applications. It offers insulation or jacketing materials, shielding options, and conductor counts so you can easily select the cable that meets your most demanding needs.
Satisfy rigorous requirements of EMI performance
Satisfy rigorous requirements of transmission distances
Flexibility
Satisfy rigorous requirements of temperature extremes
