Alpha Wire Alpha Essentials Communication & Control Control Cable, 2 Cores, 0.35 mm² 22 AWG, Screened, 1000 ft, White
- RS Stock No.:
- 277-5609
- Mfr. Part No.:
- 2824/2 WH001
- Brand:
- Alpha Wire
Subtotal (1 reel of 305 metres)*
£3,206.39
(exc. VAT)
£3,847.67
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £3,206.39 | £10.513 |
*price indicative
- RS Stock No.:
- 277-5609
- Mfr. Part No.:
- 2824/2 WH001
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Product Type | Control Cable | |
| Series | Alpha Essentials Communication & Control | |
| Number of Cores | 2 | |
| Conductor Material | Silver Plated Copper | |
| Jacket Material | Polyvinyl Chloride | |
| Jacket Colour | White | |
| Armoured | No | |
| Screened/Unscreened | Screened | |
| Cable Length | 1000ft | |
| Outside Diameter | 0.159 in | |
| Voltage | 600 Vrms | |
| Minimum Operating Temperature | -55°C | |
| Standards/Approvals | 2011/65/EU, 2015/863/EU, California Proposition 65, MIL W 16878/4, NEMA HP3 EXBFE, Regulation (EC 1907/2006) | |
| Maximum Operating Temperature | 200°C | |
| Hazardous Area Certification | Directive 2011/65/EU | |
| Cable CSA | 0.35 mm² | |
| American Wire Gauge | 22AWG | |
| Core Strands | 19 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Product Type Control Cable | ||
Series Alpha Essentials Communication & Control | ||
Number of Cores 2 | ||
Conductor Material Silver Plated Copper | ||
Jacket Material Polyvinyl Chloride | ||
Jacket Colour White | ||
Armoured No | ||
Screened/Unscreened Screened | ||
Cable Length 1000ft | ||
Outside Diameter 0.159 in | ||
Voltage 600 Vrms | ||
Minimum Operating Temperature -55°C | ||
Standards/Approvals 2011/65/EU, 2015/863/EU, California Proposition 65, MIL W 16878/4, NEMA HP3 EXBFE, Regulation (EC 1907/2006) | ||
Maximum Operating Temperature 200°C | ||
Hazardous Area Certification Directive 2011/65/EU | ||
Cable CSA 0.35 mm² | ||
American Wire Gauge 22AWG | ||
Core Strands 19 | ||
RoHS Status: Exempt
The Alpha Wire high/low temperature cables are available for temperatures ranging from -55°C to 200°C. Its high-temperature materials such as teflon will help you select the right cable for control and power applications.
Satisfy rigorous requirements of temperature extremes
