Alpha Wire Alpha Essentials Communication & Control Control Cable, 2 Cores, 0.34 mm² 22 AWG, Screened, 100 ft, Grey
- RS Stock No.:
- 277-4445
- Mfr. Part No.:
- 1736C SL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£124.68
(exc. VAT)
£149.62
(inc. VAT)
FREE delivery for orders over £50.00
- Shipping from 09 March 2026
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £124.68 | £4.156 |
*price indicative
- RS Stock No.:
- 277-4445
- Mfr. Part No.:
- 1736C SL005
- Brand:
- Alpha Wire
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Series | Alpha Essentials Communication & Control | |
| Product Type | Control Cable | |
| Number of Cores | 2 | |
| Conductor Material | Tin Copper Wire | |
| Jacket Material | Polyvinyl Chloride | |
| Jacket Colour | Grey | |
| Armoured | No | |
| Screened/Unscreened | Screened | |
| Cable Length | 100ft | |
| Outside Diameter | 0.199 in | |
| Voltage | 300 Vrms | |
| Minimum Operating Temperature | -20°C | |
| Conductor Type | Stranded | |
| Standards/Approvals | EU 2015/863/EU (RoHS3), UL AWM/STYLE 2095 CM 75°C, REACH Regulation (EC 1907/2006), California Proposition 65, CE: EU 2011/65/EU(RoHS2), CE: EU Low Voltage 2014/35/EU, CSA International CMG FT4 | |
| Maximum Operating Temperature | 80°C | |
| Cable CSA | 0.34 mm² | |
| Hazardous Area Certification | No | |
| Fire Behaviour | VW-1 | |
| American Wire Gauge | 22AWG | |
| Core Strands | 22 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Series Alpha Essentials Communication & Control | ||
Product Type Control Cable | ||
Number of Cores 2 | ||
Conductor Material Tin Copper Wire | ||
Jacket Material Polyvinyl Chloride | ||
Jacket Colour Grey | ||
Armoured No | ||
Screened/Unscreened Screened | ||
Cable Length 100ft | ||
Outside Diameter 0.199 in | ||
Voltage 300 Vrms | ||
Minimum Operating Temperature -20°C | ||
Conductor Type Stranded | ||
Standards/Approvals EU 2015/863/EU (RoHS3), UL AWM/STYLE 2095 CM 75°C, REACH Regulation (EC 1907/2006), California Proposition 65, CE: EU 2011/65/EU(RoHS2), CE: EU Low Voltage 2014/35/EU, CSA International CMG FT4 | ||
Maximum Operating Temperature 80°C | ||
Cable CSA 0.34 mm² | ||
Hazardous Area Certification No | ||
Fire Behaviour VW-1 | ||
American Wire Gauge 22AWG | ||
Core Strands 22 | ||
RoHS Status: Exempt
