Lapp OLFLEX Power Cable, 9 Cores, 0.75 mm², YY, Screened, 100m, Grey PVC Sheath
- RS Stock No.:
- 276-0952
- Mfr. Part No.:
- 0010028
- Brand:
- Lapp
Subtotal (1 reel of 100 metres)*
£222.18
(exc. VAT)
£266.62
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £222.18 | £2.222 |
*price indicative
- RS Stock No.:
- 276-0952
- Mfr. Part No.:
- 0010028
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Lapp | |
Series | OLFLEX | |
Number of Cores | 9 | |
Cross Sectional Area | 0.75 mm² | |
Sheath Material | Polyvinyl Chloride PVC | |
Sheath Colour | Grey | |
Control Cable Type | YY | |
Screened/Unscreened | Screened | |
Length | 100m | |
Select all | ||
---|---|---|
Brand Lapp | ||
Series OLFLEX | ||
Number of Cores 9 | ||
Cross Sectional Area 0.75 mm² | ||
Sheath Material Polyvinyl Chloride PVC | ||
Sheath Colour Grey | ||
Control Cable Type YY | ||
Screened/Unscreened Screened | ||
Length 100m | ||
- COO (Country of Origin):
- BG
The Lapp color coded PVC control cable for occasional flexible use and fixed installation for medium mechanical use. They are suitable for use in dry, damp and wet areas and are space saving due to smaller cable diameters. If using outdoors, observe the indicated temperature range and use with UV protection. They are largely resistant to acids, alkalis and certain oils at room temperature.
IEC 60227 5 standard
Flammability retardant
Cores are stranded in layers
EN 50525 2 11 and EN 50525 2 51 standard
Suitable for torsion application in wind turbines
Flammability retardant
Cores are stranded in layers
EN 50525 2 11 and EN 50525 2 51 standard
Suitable for torsion application in wind turbines
