Igus chainflex CF77.UL.D Control Cable, 4 Cores, 0.5 mm², Unscreened, 50m, Grey PUR Sheath, 20 AWG

Subtotal (1 reel of 50 metres)*

£118.95

(exc. VAT)

£142.75

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 300 unit(s) ready to ship
  • Plus 999,999,650 unit(s) shipping from 29 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
50 +£2.379£118.95

*price indicative


RS Stock No.:
210-0456
Mfr. Part No.:
CF77.UL.05.04.D (50m)
Brand:
Igus
Find similar products by selecting one or more attributes.
Select all

Brand

Igus

Series

chainflex CF77.UL.D

Number of Cores

4

Cross Sectional Area

0.5 mm²

American Wire Gauge

20 AWG

Conductor Material

Copper

Sheath Material

PUR

Sheath Colour

Grey

Screen Type

Unscreened

Screened/Unscreened

Unscreened

Armoured

No

Outer Diameter

6mm

Minimum Bend Radius

4 x D

Length

50m

Voltage Rating

300/500 V

Current Rating

10 A

Fire Behaviour

Flame Retardant, Halogen Free

Maximum Operating Temperature

+80°C

Conductor Resistance

39 Ω/km

Earth Cable

Yes

Insulation Material

TPE

Cable Shape

Multicore

Oil Resistant

Yes

Minimum Operating Temperature

-50°C
