RS PRO Control Cable, 4 Cores, 1.5 mm², SY, Screened, 100m, Transparent PVC Sheath
- RS Stock No.:
- 208-0522
- Brand:
- RS PRO
14 In stock - FREE next working day delivery available
1 available from Europe for delivery within 1 working day(s).
Added
Price 1 Reel of 100 Metre(s)
£238.69
(exc. VAT)
£286.43
(inc. VAT)
| Reel(s) | Per Reel | Per Metre* |
| 1 + | £238.69 | £2.387 |
| *price indicative | ||
- RS Stock No.:
- 208-0522
- Brand:
- RS PRO
Legislation and Compliance
Product Details
RS PRO Industrial Unscreened Multicore Cables, 4 x 1.5mm
Introducing industrial unscreened multicore cables from RS PRO, a range of high quality and cost-effective cables ideal for use in a wide range of electrical applications. The cables feature a multicore construction making them perfect for applications that require multiple cores to be wired, whilst keeping them organised and safe. The strands are housed in a durable PVC sheath offering excellent protection and reliability, whilst maintaining high performance. RS PRO multicore unscreened industrial cables are made with high-quality tinned copper conductor are ideal for many applications especially indoors under dry or moist conditions but if protected can also be used in outdoor conditions as well.
Features and Benefits
- 4 cores
- Unscreened making them highly cost effective and efficient
- Can be used outdoors when protected
- 1.5 mm² CSA
- High quality tinned copper conductor
- Durable PVC sheath offering excellent durability and protection
- Wide operating temperature range to accommodate various applications for your cabling
- High-performance multicore
Applications
Unscreened cables are ideal for low-frequency industrial applications, offering a cost-effective cable solution with high performance and durability. Unscreened cables are available in a wide range of lengths and can feature multiple cores to accommodate more sophisticated installations. They are featured in various types of applications including:
Entertainment and audio industry
Machines and factory control equipment
Large control pads
DIN-Rail terminals
Conveyor belts
Entertainment and audio industry
Machines and factory control equipment
Large control pads
DIN-Rail terminals
Conveyor belts
Standards
BS EN 50525-2-11:2011
Do I need a screened or unscreened cable?
Unscreened cables feature an outer cover which has been directly forced above the insulation and are ideal for electrical applications that produce low frequencies. Unscreened, the cables provide sufficient protection and high performance whilst remaining a cost-effective solution. If you need a cable for high-frequency applications then a screened cable would be more suitable.
What is multicore industrial cable?
Multicore cable is a type of electrical cable which includes more cores than a standard power or coaxial cable. They can be supplied in various lengths and the number of cores can vary significantly, depending on the type of application required. Commonly used within industrial or entertainment applications, they can keep otherwise messy and disorganised cable connections tidy and are cost effective solution.
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO seal of approval if we’re confident of their exceptional quality, which means you can be confident too.
Specifications
Attribute | Value |
|---|---|
| Number of Cores | 4 |
| Cross Sectional Area | 1.5 mm² |
| Screened/Unscreened | Screened |
| Length | 100m |
| Control Cable Type | SY |
| Sheath Colour | Transparent |
| CPR Certification | Eca |
| Outer Diameter | 11.5mm |
| Sheath Material | PVC |
| Insulation Material | PVC |
| Core Strands | 30/0.25 mm |
| Minimum Bend Radius | 6 x Diameter |
| Current Rating | 16 A |
| Conductor Material | Copper |
| Voltage Rating | 300/500 V |
| Bedding Material | PVC |
| Minimum Operating Temperature | -15°C |
| Screen Type | Galvanised Steel |
| Maximum Operating Temperature | +70°C |
- RS Stock No.:
- 208-0522
- Brand:
- RS PRO
