Alpha Wire Alpha Essentials Communication & Control Control Cable, 4 Cores, DEF STAN, Screened, 30m, Grey PVC Sheath,
- RS Stock No.:
- 187-1983
- Mfr. Part No.:
- 2464C SL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£94.50
(exc. VAT)
£113.40
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 90 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 30 + | £3.15 | £94.50 |
*price indicative
- RS Stock No.:
- 187-1983
- Mfr. Part No.:
- 2464C SL005
- Brand:
- Alpha Wire
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Series | Alpha Essentials Communication & Control | |
| Number of Cores | 4 | |
| American Wire Gauge | 22 AWG | |
| Conductor Material | Tinned Copper | |
| Sheath Material | PVC | |
| Sheath Colour | Grey | |
| Control Cable Type | DEF STAN | |
| Screened/Unscreened | Screened | |
| Screen Type | Aluminium Foil | |
| Outer Diameter | 4.62mm | |
| Minimum Bend Radius | 10 x Cable Diameter | |
| Length | 30m | |
| Voltage Rating | 300 V | |
| Maximum Operating Temperature | +75°C | |
| Insulation Material | PP | |
| Drain Wire | Yes | |
| Conductor Resistance | 16.2 Ω | |
| Core Strands | 7/30 AWG | |
| Minimum Operating Temperature | -20°C | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Series Alpha Essentials Communication & Control | ||
Number of Cores 4 | ||
American Wire Gauge 22 AWG | ||
Conductor Material Tinned Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Control Cable Type DEF STAN | ||
Screened/Unscreened Screened | ||
Screen Type Aluminium Foil | ||
Outer Diameter 4.62mm | ||
Minimum Bend Radius 10 x Cable Diameter | ||
Length 30m | ||
Voltage Rating 300 V | ||
Maximum Operating Temperature +75°C | ||
Insulation Material PP | ||
Drain Wire Yes | ||
Conductor Resistance 16.2 Ω | ||
Core Strands 7/30 AWG | ||
Minimum Operating Temperature -20°C | ||
