Igus chainflex CFBUS.LB Data Cable, 4 Cores, 0.38 mm², Screened, 25m, Green TPE Sheath, 22 AWG

RS Stock No.:: 185-4919
Mfr. Part No.:: CFBUS.LB.060
Brand:: Igus

Igus chainflex CFBUS.LB Data Cable, 4 Cores, 0.38 mm², Screened, 25m, Green TPE Sheath, 22 AWG

Available to back order for despatch 28/05/2024

Added

Price 1 Reel of 25 Metre(s)

£218.73

(exc. VAT)

£262.48

(inc. VAT)

Reel(s)	Per Reel	Per Metre*
1 +	£218.73	£8.749
*price indicative

RS Stock No.:: 185-4919
Mfr. Part No.:: CFBUS.LB.060
Brand:: Igus

Technical Reference

Legislation and Compliance

COO (Country of Origin):: DE

Product Details

Outer jacket: TPE
Overall shield
PVC-free
UV-resistant
Halogen-free
Application
For heaviest duty applications
Almost unlimited resistance to oil, also to bio-oils, Class 4
Indoor and outdoor applications without direct solar radiation
Unsupported travel distances and up to 400 m and more for gliding applications, Class 6
Bus connection cable for storage and retrieval equipment, machining units/machine tools, quick handling, clean room, semiconductor insertion, indoor cranes, low-temperature applications

Specifications

Attribute	Value
Series	chainflex CFBUS.LB
Number of Cores	4
Cross Sectional Area	0.38 mm²
Screened/Unscreened	Screened
Length	25m
Cable Shape	Multicore
Sheath Colour	Green
American Wire Gauge	22 AWG
Outer Diameter	7.5mm
Sheath Material	TPE
Standards Met	CE, CTP, DIN EN 60754, DIN EN 60811-404, DIN EN ISO 14644-1, EAC
Conductor Resistance	51 Ω/km
Armoured	No
Oil Resistant	Yes
Maximum Operating Temperature	+70°C
Screen Type	Tinned Copper Braid
Minimum Operating Temperature	-35°C
Fire Behaviour	Halogen Free
Earth Cable	No
Voltage Rating	50 V
Conductor Material	Copper
Current Rating	7 A
Minimum Bend Radius	4 x D
Insulation Material	TPE
