ABB ESB16-02N-01 ESB Contactor, 24 V Coil, 2-Pole, 16 A, 3.7 kW, 2NC

This contactor is designed to manage single loads up to 16A. Measuring 65mm in length, 18mm in width, and 65mm in depth, it offers a compact solution for both industrial and domestic applications. With a coil voltage of 24V, this safety contactor ensures reliable operation across various environments, effectively handling a power rating of 3.7 kW.

• Hum-free operation enhances user comfort during use
• Low power consumption promotes energy efficiency
• Built-in overvoltage protection increases device longevity
• Screw terminal connection simplifies installation processes
• Operates in temperatures up to 55°C, suited for high-demand environments
• Utilises DIN rail mounting for straightforward integration into existing systems

• Controls electrical loads in household settings
• Utilised in industrial automation for motor control
• Suitable for diverse requiring 24V functionality
• Integrated within distribution boards for effective load management

This unit operates effectively within temperatures ranging from -25°C to +55°C and can be stored in conditions from -40°C to +80°C, making it versatile for varied environments.

The recommended tightening torque of 0.9 N·m for the control circuit and 1.2 N·m for the main circuit ensures secure connections, minimising the risk of disconnections or failures during operation.

It supports various wire configurations including flexible and rigid connections, with compatibility for wire sizes from 0.5mm² to 10mm², allowing for versatility in installation requirements.
