ABB ESB100-40N-01 ESB Contactor, 24 V ac/dc Coil, 2-Pole, 100 A, 69.3 kW, 4NO
- RS Stock No.:
- 211-1564
- Mfr. Part No.:
- 1SAE661111R0140
- Brand:
- ABB
Subtotal (1 unit)*
£437.28
(exc. VAT)
£524.74
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £437.28 |
*price indicative
- RS Stock No.:
- 211-1564
- Mfr. Part No.:
- 1SAE661111R0140
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Coil Voltage | 24 V ac/dc | |
| Number of Poles | 2 | |
| Contact Current Rating | 100 A | |
| Range | ESB100-40N-01 | |
| Power Rating | 69.3 kW | |
| Series | ESB | |
| Function | Safety | |
| Normal State Configuration | 4NO | |
| Width | 108mm | |
| Length | 65mm | |
| Depth | 65mm | |
Select all | ||
|---|---|---|
Brand ABB | ||
Coil Voltage 24 V ac/dc | ||
Number of Poles 2 | ||
Contact Current Rating 100 A | ||
Range ESB100-40N-01 | ||
Power Rating 69.3 kW | ||
Series ESB | ||
Function Safety | ||
Normal State Configuration 4NO | ||
Width 108mm | ||
Length 65mm | ||
Depth 65mm | ||
- COO (Country of Origin):
- DE
ABB ESB Series Contactor, 24V Coil Voltage, 100A Current Rating - 1SAE661111R0140
This ABB contactor is an efficient and reliable device designed for controlling single and three-phase loads up to 100 A. The ESB100-40N-01 version is optimised for both domestic and industrial environments, ensuring versatility in application. It features a compact design with dimensions of 65mm x 108mm x 65mm, making it suitable for installation on standard DIN rails.
Features & Benefits
• Operates on 24V AC/DC for versatile control options
• Hum-free operation reduces noise in sensitive environments
• Integrated overvoltage protection enhances safety
• 4 pole configuration allows for diverse connectivity
• Designed with screw terminals for easy wiring
• High power rating of 69.3 kW supports demanding tasks
• Hum-free operation reduces noise in sensitive environments
• Integrated overvoltage protection enhances safety
• 4 pole configuration allows for diverse connectivity
• Designed with screw terminals for easy wiring
• High power rating of 69.3 kW supports demanding tasks
Applications
• Used for controlling motors in industrial setups
• Suitable for lighting and heating
• Ideal for automation processes in manufacturing
• Effective in various electrical panel installations
• Suitable for lighting and heating
• Ideal for automation processes in manufacturing
• Effective in various electrical panel installations
What is the maximum operating temperature for this device?
The contactor can operate in temperatures reaching up to +55°C, making it suitable for a range of environments.
How do the screw terminals benefit installation?
The screw terminal design allows for secure connections with a wide range of cable sizes, facilitating straightforward installation and maintenance.
What is the significance of the 4 pole configuration?
The 4 pole configuration enables multiple connection options, enhancing flexibility in load management for various applications.
How durable is this device under frequent operation?
This model boasts an electrical durability rating of 70,000 cycles, ensuring longevity and reliability in regular use.
What types of loads can this contactor control?
It is capable of controlling both single-phase and three-phase loads, making it versatile for industrial and domestic applications.
