KEMET 311 μH 15 A Common Mode Choke 20.1 mΩ

View all Common Mode Chokes
Bulk discount available

Subtotal (1 unit)*

£16.30

(exc. VAT)

£19.56

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 34 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 9£16.30
10 - 24£15.32
25 - 49£14.74
50 - 99£14.36
100 +£14.00

*price indicative

RS Stock No.:
183-6828
Mfr. Part No.:
SHBC24W-2R1A0311V
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Inductance

311μH

Product Type

Common Mode Choke

Maximum DC Current

15A

Series

SHBC

Core Material

Fe-Si-Al Dust

Test Frequency

100kHz

Packaging

Tray

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

125°C

Number of Lines

2

Automotive Standard

No

Mount Type

Through Hole

Inductance Tolerance

±20 %

Standards/Approvals

RoHS

Maximum DC Resistance

20.1mΩ

Termination Style

Solder Pad

Height

30.5mm

Depth

57.6mm

Length

57.6mm

COO (Country of Origin):
VN
The KEMET SHBC coils are normal mode chokes with a wide variety of characteristics. These coils are designed with Fe-Si-Al dust cores and are useful in various fields such as DC/DC converters as well as normal noise countermeasures.

Fe-Si-Al dust core material

Available for smoothing and converting

Low core loss

High frequency drive

Wide variety of sizes and specifications

Operating temperature range from−40°C to +125°C

Applications

Switching power supply outlet

DC-DC converter

Phase compensation

Boost converter
