Samtec HD-BNC Series Edge Male BNC, 75 Ω, Straight Body Edge Mount
- RS Stock No.:
- 225-6223
- Mfr. Part No.:
- HDBNC-J-P-GN-ST-EM1
- Brand:
- Samtec
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£5.98
(exc. VAT)
£7.18
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 3 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £5.98 |
| 10 - 24 | £5.38 |
| 25 - 49 | £4.90 |
| 50 - 99 | £4.48 |
| 100 + | £4.00 |
*price indicative
- RS Stock No.:
- 225-6223
- Mfr. Part No.:
- HDBNC-J-P-GN-ST-EM1
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Product Type | BNC Connector | |
| Coaxial Connector Type | BNC | |
| Mount Type | Edge | |
| Impedance | 75Ω | |
| Orientation | Straight | |
| Connector Gender | Male | |
| Size | Standard | |
| Bulkhead | No | |
| Operating Frequency | 12GHz | |
| Body Plating | Gold Plated | |
| Minimum Operating Temperature | -65°C | |
| Termination Type | Edge Mount | |
| Polarity | Normal | |
| Maximum Operating Temperature | 125°C | |
| Series | HD-BNC | |
| Contact Gender | Male | |
| Contact Material | Copper Alloy | |
| Standards/Approvals | No | |
| Contact Plating | Gold | |
| Select all | ||
|---|---|---|
Brand Samtec | ||
Product Type BNC Connector | ||
Coaxial Connector Type BNC | ||
Mount Type Edge | ||
Impedance 75Ω | ||
Orientation Straight | ||
Connector Gender Male | ||
Size Standard | ||
Bulkhead No | ||
Operating Frequency 12GHz | ||
Body Plating Gold Plated | ||
Minimum Operating Temperature -65°C | ||
Termination Type Edge Mount | ||
Polarity Normal | ||
Maximum Operating Temperature 125°C | ||
Series HD-BNC | ||
Contact Gender Male | ||
Contact Material Copper Alloy | ||
Standards/Approvals No | ||
Contact Plating Gold | ||
RoHS Status: Not Applicable
The Samtec offers cable connectors with bayonet, threaded, and push-on coupling features; available for a wide variety of industry standard cables. High-frequency cable connectors are manufactured with a precise tolerance interface to ensure superior repeatability and high mechanical stability.
Optimized for 12G-SDI Broadcast Video solutions
75 ohm impedance
Low profile, right-angle mixed technology die cast bulkhead jack
