SMC Aluminium Threaded Threaded R Bushing Check Valve 1/4 in, 10 bar
- RS Stock No.:
- 234-4135
- Mfr. Part No.:
- AKB02A-02S
- Brand:
- SMC
Subtotal (1 unit)*
£13.97
(exc. VAT)
£16.76
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 3 unit(s) ready to ship
- Plus 8 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £13.97 |
*price indicative
- RS Stock No.:
- 234-4135
- Mfr. Part No.:
- AKB02A-02S
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Outlet Connection Type | Threaded | |
| Sub Type | Bushing | |
| Product Type | Check Valve | |
| Inlet Connection Type | Threaded | |
| Inlet Port Size | 1/4 in | |
| Body Material | Aluminium | |
| Maximum Operating Pressure | 10 bar | |
| Outlet Port Size | 1/4 in | |
| Inlet Thread Standard | R | |
| Inlet Port Gender | Male | |
| Outlet Thread Standard | R | |
| Outlet Port Gender | Female | |
| Minimum Operating Temperature | -5°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Outlet Connection Type Threaded | ||
Sub Type Bushing | ||
Product Type Check Valve | ||
Inlet Connection Type Threaded | ||
Inlet Port Size 1/4 in | ||
Body Material Aluminium | ||
Maximum Operating Pressure 10 bar | ||
Outlet Port Size 1/4 in | ||
Inlet Thread Standard R | ||
Inlet Port Gender Male | ||
Outlet Thread Standard R | ||
Outlet Port Gender Female | ||
Minimum Operating Temperature -5°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- JP
The SMC series AK check valves offer various configurations to provide design solutions based on operating conditions. The series is compact and lightweight with low cracking pressure.
Check valve with high flow capacity
Low cracking pressure (0.02MPa)
Compact and lightweight
Variety of models
