SMC Brass Threaded Threaded R Bushing Check Valve 1/8 in, 10 bar
- RS Stock No.:
- 234-4133
- Mfr. Part No.:
- AKB01A-01S
- Brand:
- SMC
Subtotal (1 unit)*
£10.72
(exc. VAT)
£12.86
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 40 unit(s) shipping from 02 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £10.72 |
*price indicative
- RS Stock No.:
- 234-4133
- Mfr. Part No.:
- AKB01A-01S
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Inlet Connection Type | Threaded | |
| Outlet Connection Type | Threaded | |
| Sub Type | Bushing | |
| Product Type | Check Valve | |
| Inlet Port Size | 1/8 in | |
| Body Material | Brass | |
| Maximum Operating Pressure | 10 bar | |
| Outlet Port Size | 1/8 in | |
| Inlet Thread Standard | R | |
| Inlet Port Gender | Male | |
| Outlet Port Gender | Female | |
| Minimum Operating Temperature | -5°C | |
| Outlet Thread Standard | R | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Inlet Connection Type Threaded | ||
Outlet Connection Type Threaded | ||
Sub Type Bushing | ||
Product Type Check Valve | ||
Inlet Port Size 1/8 in | ||
Body Material Brass | ||
Maximum Operating Pressure 10 bar | ||
Outlet Port Size 1/8 in | ||
Inlet Thread Standard R | ||
Inlet Port Gender Male | ||
Outlet Port Gender Female | ||
Minimum Operating Temperature -5°C | ||
Outlet Thread Standard R | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- JP
The SMC series AK check valves offer various configurations to provide design solutions based on operating conditions. The series is compact and lightweight with low cracking pressure.
Check valve with high flow capacity
Low cracking pressure (0.02MPa)
Compact and lightweight
Variety of models
