    RS PRO 20VA 2 Output Chassis Mounting Transformer, 6.3V ac

    RS Stock No.:
    504-561
    Brand:
    RS PRO
    RS PRO
    View this category
    59 In stock - FREE next working day delivery available
    9 available from Europe for delivery within 1 working day(s).
    Add to Basket
    Units

    Added

    Price Each

    £13.10

    (exc. VAT)

    £15.72

    (inc. VAT)

    UnitsPer unit
    1 - 24£13.10
    25 +£12.84
    RS Stock No.:
    504-561
    Brand:
    RS PRO
    COO (Country of Origin):
    PL

    Technical Reference


    Legislation and Compliance

    COO (Country of Origin):
    PL

    Product Details

    Chassis Mount, Clamp Construction, 230Vac, 6VA to 50VA

    Chassis mounting low voltage mains transformers with a single 230Va.c. 50/60Hz primary winding. The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.

    Features and Benefits

    "Double section bobbin construction
    Fully shrouded bobbins
    Full varnish impregnation
    Two hole fixing wrap-over clamps
    Solder tag terminations
    Optional terminal shrouds (example 503-912 )
    100% electrical and flash tested
    Tested in accordance with BS3535 and EN 60 742"

    Standards

    BS3535; EN 60 742

    Specifications

    AttributeValue
    Primary Voltage Rating230V ac
    Secondary Voltage Rating6.3V ac
    Power Rating20VA
    Number of Outputs2
    Mounting TypeClamp Mount
    Length59mm
    Width57mm
    Depth50mm
    Dimensions59 x 57 x 50mm
    Fixing Hole Diameter4.7 x 8.7mm
    Weight550g
    Minimum Operating Frequency50Hz
    Maximum Operating Frequency60Hz
