Banner Capacitive switch Momentary NO Illuminated, Yellow, Green, Red, PNP, IP67
- RS Stock No.:
- 285-937
- Mfr. Part No.:
- K50APT2GRYF2Q
- Brand:
- Banner
Subtotal (1 unit)*
£209.18
(exc. VAT)
£251.02
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 16 unit(s) shipping from 30 March 2026
- Plus 9 unit(s) shipping from 08 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £209.18 |
*price indicative
- RS Stock No.:
- 285-937
- Mfr. Part No.:
- K50APT2GRYF2Q
- Brand:
- Banner
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Banner | |
| Product Type | Capacitive switch | |
| Switch Operation | Momentary | |
| Switch Type | Capacitive | |
| Switch Function | NO | |
| Housing Material | Polycarbonate | |
| LED Colour | Yellow, Green, Red | |
| Illuminated | Yes | |
| Maximum Input Voltage | 30V | |
| Output Type | PNP | |
| Minimum Input Voltage | 12V | |
| Housing Colour | Black | |
| Series | EZ-LIGHT Touch Gen 2 K50 | |
| IP Rating | IP67 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 50°C | |
| Depth | 50mm | |
| Standards/Approvals | CAN ICES-3 (B)/NMB-3(B), FCC Part 15 | |
| Height | 41.6mm | |
| Width | 76 mm | |
| Current Rating | 150 mA | |
| Select all | ||
|---|---|---|
Brand Banner | ||
Product Type Capacitive switch | ||
Switch Operation Momentary | ||
Switch Type Capacitive | ||
Switch Function NO | ||
Housing Material Polycarbonate | ||
LED Colour Yellow, Green, Red | ||
Illuminated Yes | ||
Maximum Input Voltage 30V | ||
Output Type PNP | ||
Minimum Input Voltage 12V | ||
Housing Colour Black | ||
Series EZ-LIGHT Touch Gen 2 K50 | ||
IP Rating IP67 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 50°C | ||
Depth 50mm | ||
Standards/Approvals CAN ICES-3 (B)/NMB-3(B), FCC Part 15 | ||
Height 41.6mm | ||
Width 76 mm | ||
Current Rating 150 mA | ||
- COO (Country of Origin):
- MX
The Banner Multicolor indicator features three independent colors in one unit, providing clear visual signals with priority given to higher-numbered colors (Color 3 overrides Color 2, and Color 2 overrides Color 1). It is rugged, waterproof (IP69K), and resistant to false triggering from environmental factors like water spray, oils, and detergents, making it ideal for washdown environments
Available with PNP and NPN inputs/outputs, depending on model
Compact models available for lower profile applications
