Eaton, 4P 2 Position 45° On-Off Cam Switch, 690V (Volts), 20A, Toggle Actuator
- RS Stock No.:
- 271-5648
- Mfr. Part No.:
- 050980 T0-2-15907/Z/SVC(C,E,G-J)
- Brand:
- Eaton
Available to back order for despatch 11/09/2024
Price Each
£57.91
(exc. VAT)
£69.49
(inc. VAT)
Units | Per unit |
|---|---|
| 1 + | £57.91 |
- RS Stock No.:
- 271-5648
- Mfr. Part No.:
- 050980 T0-2-15907/Z/SVC(C,E,G-J)
- Brand:
- Eaton
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
The Eaton changeover control switch is type of electrical switch operated by rotation. The switch allow the user to turn a knob or shaft that increases or decreases the resistance conducted through the contacts depending on the direction of the turn.
Standards IEC/EN 60947
VDE approved
Switch-disconnector according to IEC/EN 60947-3
Part group reference T0
VDE approved
Switch-disconnector according to IEC/EN 60947-3
Part group reference T0
Specifications
Attribute | Value |
|---|---|
| Cam Switch Type | On-Off Cam Switch |
| Series | T0 |
| Pole and Throw Configuration | 4P |
| Electrical Phase | 3 |
| Maximum Current | 20A |
| Maximum Voltage | 690V (Volts) |
| Number of Positions | 2 |
| Angle of Throw | 45° |
| Actuator Type | Toggle |
