Eaton 4 Position 45 °, Toggle Actuator 20 A
- RS Stock No.:
- 103-8436
- Distrelec Article No.:
- 135-11-937
- Mfr. Part No.:
- 050716 T0-2-8241/E
- Brand:
- Eaton
Subtotal (1 unit)*
£27.22
(exc. VAT)
£32.66
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £27.22 |
*price indicative
- RS Stock No.:
- 103-8436
- Distrelec Article No.:
- 135-11-937
- Mfr. Part No.:
- 050716 T0-2-8241/E
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Cam Switch | |
| Series | T0 | |
| Electrical Phase | 3, 1 | |
| Number of Positions | 4 | |
| Mount Type | Flush | |
| Terminal Type | Screw | |
| Number of Poles | 1 | |
| Angle of Throw | 45 ° | |
| IP Rating | IP65 | |
| Minimum Operating Temperature | -25°C | |
| Contact Current | 20A | |
| Actuator Type | Toggle | |
| Contact Voltage | 690V ac | |
| Maximum Operating Temperature | 50°C | |
| Width | 48mm | |
| Depth | 48mm | |
| Hazardous Area Certification | NO | |
| Standards/Approvals | VDE 0660, IEC/EN 60204, UL 60947-4-1, CE marking, IEC/EN 60947, CSA, IEC/EN 60947-3, UL, CSA-C22.2 No. 94, CSA - C22.2 No. 60947-4-1-14 | |
| Length | 48mm | |
| Mechanical Life | 10000000Operations | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Cam Switch | ||
Series T0 | ||
Electrical Phase 3, 1 | ||
Number of Positions 4 | ||
Mount Type Flush | ||
Terminal Type Screw | ||
Number of Poles 1 | ||
Angle of Throw 45 ° | ||
IP Rating IP65 | ||
Minimum Operating Temperature -25°C | ||
Contact Current 20A | ||
Actuator Type Toggle | ||
Contact Voltage 690V ac | ||
Maximum Operating Temperature 50°C | ||
Width 48mm | ||
Depth 48mm | ||
Hazardous Area Certification NO | ||
Standards/Approvals VDE 0660, IEC/EN 60204, UL 60947-4-1, CE marking, IEC/EN 60947, CSA, IEC/EN 60947-3, UL, CSA-C22.2 No. 94, CSA - C22.2 No. 60947-4-1-14 | ||
Length 48mm | ||
Mechanical Life 10000000Operations | ||
Eaton Rotary Switch, Screw Terminal Type, 6kV Impulse Withstand Voltage - T0 Series - 050716 T0-2-8241/E
Choose this rotary switch from Eaton and you'll find cycling your circuit through multiple modes is a cinch. The unit's 1-pole, 4-position configuration lets you step a single piece of equipment from its off position through three different operating states simply by turning it 45º. As it supports both AC and DC switching and works with battery or mains-powered devices, this is a versatile option. Thanks to an impulse withstand voltage rating of 6kV, you can rest assured that it can safely handle even significant electrical surges.
• Resists mechanical shock, so it's a safe bet for use in demanding industrial environments with moving machinery
• Suits an ambient temperature range of -25ºC to +50ºC, meaning it tolerates extremes of heat and cold
• IP65 rating tells you it's dustproof and resistant to low-pressure jets of water from any angle
• Reliable screw terminals help you make robust electrical connections
Does this switch come with short-circuit protection?
This switch offers short-circuit protection when you pair it up with a suitable gG or gL-type fuse.
Note
Eaton formerly known as Moeller
