JST , AF Insulated Crimp Blade Terminal 10mm Blade Length, 2.6mm² to 6.6mm², 12AWG to 10AWG, Yellow
- RS Stock No.:
- 838-8175
- Mfr. Part No.:
- FVWS5.5-1AF(LF)
- Brand:
- JST
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 100)
£0.311
(exc. VAT)
£0.373
(inc. VAT)
- RS Stock No.:
- 838-8175
- Mfr. Part No.:
- FVWS5.5-1AF(LF)
- Brand:
- JST
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | JST | |
| Series | AF | |
| Gender | Male | |
| Insulation | Insulated | |
| Insulation Material | Vinyl | |
| Shrouded/Unshrouded | Shrouded | |
| Minimum Wire Size mm² | 2.6mm² | |
| Maximum Wire Size mm² | 6.6mm² | |
| Minimum Wire Size AWG | 12AWG | |
| Overall Length | 23.5mm | |
| Maximum Wire Size AWG | 10AWG | |
| Inner Diameter | 6.8mm | |
| Blade Length | 10mm | |
| Blade Width | 2.8mm | |
| Blade Thickness | 1mm | |
| Hooked | No | |
| Colour | Yellow | |
Select all | ||
|---|---|---|
Brand JST | ||
Series AF | ||
Gender Male | ||
Insulation Insulated | ||
Insulation Material Vinyl | ||
Shrouded/Unshrouded Shrouded | ||
Minimum Wire Size mm² 2.6mm² | ||
Maximum Wire Size mm² 6.6mm² | ||
Minimum Wire Size AWG 12AWG | ||
Overall Length 23.5mm | ||
Maximum Wire Size AWG 10AWG | ||
Inner Diameter 6.8mm | ||
Blade Length 10mm | ||
Blade Width 2.8mm | ||
Blade Thickness 1mm | ||
Hooked No | ||
Colour Yellow | ||
JST Insulated Crimp Blade Terminals
A range of insulated crimp blade terminals suitable for a variety of wire size ranges.
Insulated crimp blade terminals with part number prefix 'FVWS' have a butted seam and flared vinyl insulation
Insulated crimp blade terminals with part number prefix 'FVDWS' have a butted seam, copper sleeve and vinyl insulation
Insulated crimp blade terminals with part number prefix 'FVWS' have a butted seam and flared vinyl insulation
Insulated crimp blade terminals with part number prefix 'FVDWS' have a butted seam, copper sleeve and vinyl insulation
JST Insulated Crimp Terminals
