Toshiba 2SC5200N(S1,E,S) Transistor, 15 A NPN, 230 V, 3-Pin TO-3P
- RS Stock No.:
- 890-2689
- Mfr. Part No.:
- 2SC5200N(S1,E,S)
- Brand:
- Toshiba
Bulk discount available
View bulk pricing optionsSubtotal (1 pack of 5 units)*
£8.55
(exc. VAT)
£10.25
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 350 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £1.71 | £8.55 |
| 25 - 45 | £1.29 | £6.45 |
| 50 - 120 | £1.156 | £5.78 |
| 125 - 245 | £1.066 | £5.33 |
| 250 + | £1.036 | £5.18 |
*price indicative
- RS Stock No.:
- 890-2689
- Mfr. Part No.:
- 2SC5200N(S1,E,S)
- Brand:
- Toshiba
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Toshiba | |
| Product Type | Transistor | |
| Maximum DC Collector Current Idc | 15A | |
| Maximum Collector Emitter Voltage Vceo | 230V | |
| Package Type | TO-3P | |
| Mount Type | Through Hole | |
| Transistor Configuration | Single | |
| Maximum Collector Base Voltage VCBO | 230V | |
| Minimum Operating Temperature | -55°C | |
| Maximum Transition Frequency ft | 30MHz | |
| Maximum Power Dissipation Pd | 150W | |
| Transistor Polarity | NPN | |
| Minimum DC Current Gain hFE | 35 | |
| Maximum Emitter Base Voltage VEBO | 5V | |
| Pin Count | 3 | |
| Maximum Operating Temperature | 150°C | |
| Standards/Approvals | No | |
| Height | 40.5mm | |
| Length | 15.5mm | |
| Series | 2SC5200N | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Toshiba | ||
Product Type Transistor | ||
Maximum DC Collector Current Idc 15A | ||
Maximum Collector Emitter Voltage Vceo 230V | ||
Package Type TO-3P | ||
Mount Type Through Hole | ||
Transistor Configuration Single | ||
Maximum Collector Base Voltage VCBO 230V | ||
Minimum Operating Temperature -55°C | ||
Maximum Transition Frequency ft 30MHz | ||
Maximum Power Dissipation Pd 150W | ||
Transistor Polarity NPN | ||
Minimum DC Current Gain hFE 35 | ||
Maximum Emitter Base Voltage VEBO 5V | ||
Pin Count 3 | ||
Maximum Operating Temperature 150°C | ||
Standards/Approvals No | ||
Height 40.5mm | ||
Length 15.5mm | ||
Series 2SC5200N | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
NPN Power Transistors, Toshiba
Bipolar Transistors, Toshiba
