SKF Bearing Insert 23.813 mm ID 52 mm OD YAR 205-015-2F
- RS Stock No.:
- 463-396
- Mfr. Part No.:
- YAR 205-015-2F
- Brand:
- SKF
Subtotal (1 unit)*
£31.29
(exc. VAT)
£37.55
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £31.29 |
*price indicative
- RS Stock No.:
- 463-396
- Mfr. Part No.:
- YAR 205-015-2F
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 23.813 mm | |
| Product Type | Bearing Insert | |
| Outside Diameter | 52 mm | |
| Material | Steel | |
| Static Load Rating | 7.8kg | |
| Dynamic Load Rating | 14kN | |
| Locking Type | Screw | |
| Bore Type | Cylindrical | |
| Standards/Approvals | RoHS | |
| Series | YAR 205-015-2F | |
| Overall Width | 34.1mm | |
| Limiting Speed | 7000rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 23.813 mm | ||
Product Type Bearing Insert | ||
Outside Diameter 52 mm | ||
Material Steel | ||
Static Load Rating 7.8kg | ||
Dynamic Load Rating 14kN | ||
Locking Type Screw | ||
Bore Type Cylindrical | ||
Standards/Approvals RoHS | ||
Series YAR 205-015-2F | ||
Overall Width 34.1mm | ||
Limiting Speed 7000rpm | ||
- COO (Country of Origin):
- IT
The SKF Insert bearings are based on sealed deep groove ball bearings. This variant is suitable for applications with both constant and alternating directions of rotation. It has an inner ring extended on both sides and is locked onto the shaft by tightening two (set) screws on the inner ring, making it easy to mount.
Designed for a constant and alternating rotation
Quick and easy to mount onto the shaft
Reduce noise and vibration levels
