SKF Insert Bearing 50 mm ID 69.06 mm OD FYJ 55 KF

View all Bearing Inserts

Subtotal (1 unit)*

£124.50

(exc. VAT)

£149.40

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 24 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£124.50

*price indicative

RS Stock No.:
461-591
Mfr. Part No.:
FYJ 55 KF
Brand:
SKF
Find similar products by selecting one or more attributes.
Select all

Brand

SKF

Inside Diameter

50 mm

Product Type

Insert Bearing

Outside Diameter

69.06 mm

Material

Cast Iron

Static Load Rating

29kN

Dynamic Load Rating

43.6kN

Series

FYJ 55 KF

Overall Width

57.5mm

Standards/Approvals

RoHS

Bore Type

Tapered

Limiting Speed

3600rpm

COO (Country of Origin):
IT

Akshay


The SKF Square flanged ball bearing units are compliant with Japanese Industrial Standards (JIS). They consist of an insert bearing, locked to the shaft with an adapter sleeve, which enables the bearings to operate at higher speeds and run more smoothly in applications where the direction of rotation is constant or alternating. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement. The adapter sleeve is not included in the unit and should be ordered separately.

Resist high levels of contamination

Designed for high temperatures and speeds

Accommodate relatively heavy loads

Cost-effective
