SKF Insert Bearing 50 mm ID 69.06 mm OD FYJ 55 KF
- RS Stock No.:
- 461-591
- Mfr. Part No.:
- FYJ 55 KF
- Brand:
- SKF
Subtotal (1 unit)*
£124.50
(exc. VAT)
£149.40
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 25 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £124.50 |
*price indicative
- RS Stock No.:
- 461-591
- Mfr. Part No.:
- FYJ 55 KF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 50 mm | |
| Product Type | Insert Bearing | |
| Outside Diameter | 69.06 mm | |
| Material | Cast Iron | |
| Static Load Rating | 29kN | |
| Dynamic Load Rating | 43.6kN | |
| Overall Width | 57.5mm | |
| Bore Type | Tapered | |
| Standards/Approvals | RoHS | |
| Series | FYJ 55 KF | |
| Limiting Speed | 3600rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 50 mm | ||
Product Type Insert Bearing | ||
Outside Diameter 69.06 mm | ||
Material Cast Iron | ||
Static Load Rating 29kN | ||
Dynamic Load Rating 43.6kN | ||
Overall Width 57.5mm | ||
Bore Type Tapered | ||
Standards/Approvals RoHS | ||
Series FYJ 55 KF | ||
Limiting Speed 3600rpm | ||
- COO (Country of Origin):
- IT
Akshay
The SKF Square flanged ball bearing units are compliant with Japanese Industrial Standards (JIS). They consist of an insert bearing, locked to the shaft with an adapter sleeve, which enables the bearings to operate at higher speeds and run more smoothly in applications where the direction of rotation is constant or alternating. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement. The adapter sleeve is not included in the unit and should be ordered separately.
Resist high levels of contamination
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost-effective
